SCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe Fittings
SCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe Fittings
SCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe Fittings
SCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe Fittings
SCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe Fittings
SCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe Fittings
Specifications
Brand Name :
zexu
Model Number :
1"-80"
Certification :
CE API ISO9001
Place of Origin :
Hebei china
MOQ :
1pcs
Price :
20-27000USD
Payment Terms :
T/T
Supply Ability :
30000ton/Year
Delivery Time :
5work days
Packaging Details :
Export wooden box
Thread Type :
NPT BSP BSPT
Technics :
Forged, FORGED
Connection :
Welding
Shape :
Equal
Application :
Industry
Head Code :
round
Material :
A105
Color :
black or varnished
Description

ASTM A105 45° Socket Elbow Petrochemical High Pressure Pipe Connection Fittings

According to the form, it is divided into 45° socket elbow and 90° socket elbow
According to common standards, the specifications of socket elbows are DN6, DN8, DN10, DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100. The commonly used order specification is DN15----DN50. If the specifications are beyond the scope, we can communicate with customers on the design and processing of drawings.
Pressure Level
According to the pressure level: 3000LB, 6000LB, 9000LB or SCH80, SCH160, XXS

Mainly suitable for petrochemical, medical and health, electric power, aerospace, military, fire protection, metallurgy, shipbuilding, gas, nuclear power, and environmental protection departments and fields that require high pressure and precision dimensions.

Forged Pipe Elbow Supply Range

Forged steel elbow is consist of threaded elbow and socket weld elbow. Except the pressure of socket weld elbow is Class 3000, 6000 and 9000, socket weld elbow and threaded elbow are available in the same dimension ranges.

Size 1/8", 1/4", 3/8", 1/2", 1/4", 1", 1 1/4", 1 1/2", 2", 2 1/2", 3", 4"
Pressure 2000lb, 3000lb, 6000lb
Thread NPT, BSPP, BSPT, As Requirement
Type 90 Degree Elbow, 45 Degree Elbow
Standard ASME B16.11, BS 3799, DIN, JIS, As Request
Nominal Diameter Depth of Socket Dimension of Socket Wall Thickness Center to Bottom of Socket
A
Cmin 90°Elbow,Tee,Cross 45°Elbow
DN NPS Jmin d1 3000LB 6000LB 9000LB 3000LB 6000LB 9000LB 3000LB 6000LB 9000LB
Sch80 Sch160 XXS Sch80 Sch160 XXS Sch80 Sch160 XXS
6 1/8 10 10.7 3.2 3.5 - 11 11 - 8 8 -
8 1/4 10 14.1 3.3 4 - 11 15 - 8 8 -
10 3/8 10 17.5 3.5 4.4 - 13 15 - 8 12 -
15 1/2 10 21.8 4.1 5.2 8.2 16 19 25 11 13 16
20 3/4 13 27.4 4.3 6.1 8.6 19 22 28 13 14 18
25 1 13 34.2 5 7 10 22 27 32 14 18 22
32 1.1/4 13 42.9 5.3 7 10.6 27 32 35 18 21 22
40 1.1/2 13 48.3 5.6 7.8 11.2 32 38 38 21 25 25
50 2 13 61.1 6.1 9.5 12.2 38 41 41 25 29 29
65 2.1/2 16 76.9(73.8) 7.7 12.5 - 41 57 - 29 32 -
80 3 16 89.8 8.3 13.8 - 57 64 - 32 35 -
100 4 19 115.5 9.4 - - 66 - - 42 - -

SCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe FittingsSCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe FittingsSCH80 A105 45 Degree Socket Weld Elbow , Petrochemical Pipe Fittings
