Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant
Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant
Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant
Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant
Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant
Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant
Specifications
Brand Name :
Ze Xu
Model Number :
1/2"-80”
Certification :
ISO9000
Place of Origin :
Yanshan, Hebei, China
MOQ :
1Pcs
Price :
USD 10 per piece
Payment Terms :
T/T
Supply Ability :
100,0000 tons per month
Delivery Time :
3-7 Working day
Packaging Details :
Wooden box, pallet or according to customer requirements
Material :
Plastic,Stainless Steel
Technics :
Butt weld
Shape :
Equal,Reducing,Round
Head code :
Round
Connection :
Welding
Type :
Reducer
Standard :
ANSI,ASME,DIN,JIC/BSP/NPT/BSPT/SAE/Metric/ORFS,SCH40
Usage :
Oil Gas Water Industrial,Convey Water,Sanitary Construction,Joining Pipe Lines,Steel pipe
Description

Power Plant Special Pipe Reducer 10CrMoAl Seawater Corrosion Resistant Pipe Reducer Alloy Pipe Reducer

Features and applications:


It is a special steel that is resistant to seawater corrosion. 10CrMoAl material is the most ideal material for pipelines and processed parts for coastal power plants, coastal oil fields, coastal natural gas and petrochemical plants to transport water, oil and gas and seawater-containing media. It can also be used to make valve flanges.

chemical composition:

unit(%)

Grade
C
Mn
Ni
Si
P
S
Cr
Cu
Mo
Al
10CrMoAl
≤0.12
0.35-0.65
≤0.03
0.2-0.5
≤0.025
≤0.025
0.8-1.2
≤0.03
0.2-0.35
0.4-0.8

Mechanical properties:

Grade
Tensile strength (MPa)
Yield strength (MPa)
Elongation(%)
10CrMoAl
≥490
≥323
≥17

use:


Material, mainly used to make pipes and equipment. It has the advantages of strong corrosion resistance and convenient installation.

Reasons for corrosion resistance:
1. The Al (aluminum) in the 10CrMoAl material can chemically react with the O (oxygen) in the air to form Al2O3 (aluminum trioxide). This forms a protective film, which is both corrosion-resistant and corrosion-resistant.


2. The Cr (chromium) and Mo (molybdenum) ions in 10CrMoAl can automatically supplement the gaps formed by the pitting corrosion of Cl (chlorine) ions on the steel in the seawater, forming a dense protective layer to prevent the pitting corrosion from developing in depth. In turn, it is resistant to corrosion and prolongs the service life.


welding:


The 10CrMoAl material has better welding performance and is equipped with a special corrosion-resistant electrode "sea O3", without special welding requirements.

Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant

Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant

Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant

Power Plant Special Pipe Fittings Reducer 10crmoal Alloy Seawater Corrosion Resistant
