DIN3352 EN1171 Ductile Iron NRS Resilient Gate Valves For Water
DIN3352 EN1171 Ductile Iron NRS Resilient Gate Valves For Water
DIN3352 EN1171 Ductile Iron NRS Resilient Gate Valves For Water
DIN3352 EN1171 Ductile Iron NRS Resilient Gate Valves For Water
DIN3352 EN1171 Ductile Iron NRS Resilient Gate Valves For Water
DIN3352 EN1171 Ductile Iron NRS Resilient Gate Valves For Water
Specifications
Brand Name :
DEYE
Model Number :
DY-GV-Z-1
Certification :
ISO9001:2015 PED
Place of Origin :
CHINA
MOQ :
10PCS
Price :
USD2-USD20000 each
Payment Terms :
T/T, L/C, D/P
Supply Ability :
1000pcs one month
Delivery Time :
20 days for usual order, 7 days for stocked items
Packaging Details :
carton box+ ply wooden cases or carton+ Pallets
Description

Ductile Iron Nrs Resilient Gate Valves For Water

Model No. GV-Z-1

ductile iron DIN PN16 Flat resilient Gate valve for drinking Water. Temperature: -30℃-+125℃

Gate Valves Quick Detail

Gland Gate valve

Material Iron
Design standard DIN3352 EN1171, BS5163, AWWAC515
End connection RF. Flange
Face to face DIN33352 F4 short type,F5 Long Type, BS5163, AWWAC515
Working temperature -30℃~+125℃
Test and inspection API 598
Product Range Size 2"-48" DN50-DN1200
Connection Flange ends conform to EN1092-1
Inside and outside FEB coating Min 250 Microns

Gate Valves Range:

Available Body Material: Cast Iron GG25, Ductile iron GGG40, GGG50

Available Disc Material: Ductile iron, Bronze

Optional Seat Ring: EPDM, NBR, Brass, Bronze, SS304, SS316

Optional Design: DIN /BS/ ANSI with difference Face to face length

Optional Ends: BS4504/EN1092-1 PN16/ ANSI B16.5 RF

Size Range: DN50-DN1200 (2”-48”)

Pressure Range: PN10, PN16, 150LBS.

Optional surface color: RAL5002, RAL5015. RAL5005, red, black. Or customized

Optional Operation: Handwheel /Chain wheel/ electric Actuator/pneumatic actuator

Performance

• PN10/16/PN25/150PSI/225PSI Resilient Seated Gate Valve is operating by the EPDM covered iron wedge

moving perpendicular to the flow axis through a worm machined stem multi turned

• 100% tight sealing is achieved through EPDM covered wedge fully contacting

The fusion bonded epoxy coated flow surface

• In each time the valve is opened, the flow on the line cleans the sealing surface,

Prevents from dirt and deposits

• With its short installation length ( DIN 3202 F4), does not occupy a big place

• It has ductile iron body and stainless steel stem

• Inner and outer surfaces are coated with minimum 250 microns fusion bonded epoxy

• Suitable to install actuator and gearbox

• Suitable to use with ground and underground applications. Can be operated with extension spindle

• Very low head loss rating. Can be operated with lower torque ratings, no maintenance needed

Technical Data Sheets:

DIN3352 EN1171 Ductile Iron NRS Resilient Gate Valves For Water

Applications

Gate Valves Used For Hot Water, Cold Water, Fluids without acidity or alkalinity properties
