GGG40 GGG50 Ductile Iron Socket Ends Gate Valve For Pvc Pipe Connection

Model No. GV-Z-14

ductile iron socket welded Gate valve for PVC HDPE pipes. Temperature: -30℃-+125℃

Quick Detail

Design standard: DIN

Body material: Ductile iron GGG50

Wedge: Ductile iron + EPDM/NBR

Pressure: PN16

End connection: SW socket welded

Face to face: DIN33352 F5

Working temperature: -30℃~+125℃.

Test and inspection: API 598.

Gland Gate valve

Product Range Size: 2"-14" 50mm-355mm

Connection: Flange ends conform to EN1092-1

Product Range

Available Body Material: Cast Iron GG25, Ductile iron GGG40, GGG50

Optional Wedge Seat: EPDM, NBR

Optional Design: DIN /SABS with difference Face to face length

Optional Ends: SW for PVC pipes/ PE pipes/ HDPE pipes/ Plastic Pipes

Size Range: 50mm- 355mm (2”-14”)

Pressure Range: PN10, PN16

Optional surface color: RAL5002, RAL5015. RAL5005, red Or customized

Optional Operation: square Nut, Handwheel

Performance:

• PN10/16 Resilient Seated Gate Valve is operating by the EPDM covered iron wedge

moving perpendicular to the flow axis through a worm machined stem multi turned

• 100% tight sealing is achieved through EPDM covered wedge fully contacting

The fusion bonded epoxy coated flow surface

• In each time the valve is opened, the flow on the line cleans the sealing surface,

Prevents from dirt and deposits

• With its short installation length ( DIN 3202 F5), does not occupy a big place

• It has ductile iron body and stainless steel stem

• Inner and outer surfaces are coated with minimum 250 microns fusion bonded epoxy

• Suitable to install actuator and gearbox

• Suitable to use with ground and underground applications. Can be operated with extension spindle

• Very low head loss rating. Can be operated with lower torque ratings, no maintenance needed

Technical Data Sheets

Gate Valve For Pvc Pipe Connection Applications

Gate Valve uesd for Hot Water, Cold Water, Fluids without acidity or alkalinity properties
