750L Current Planetary Cement Mixer Refractory Bricks Sand Mixing 1 Bottom Scraper
750L Current Planetary Cement Mixer Refractory Bricks Sand Mixing 1 Bottom Scraper
750L Current Planetary Cement Mixer Refractory Bricks Sand Mixing 1 Bottom Scraper
750L Current Planetary Cement Mixer Refractory Bricks Sand Mixing 1 Bottom Scraper
Specifications
Brand Name :
PERMIX
Model Number :
PMC750
Certification :
CE
Place of Origin :
JIAOZHOU CHINA
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
5-10 units per month
Delivery Time :
5-8 days
Packaging Details :
Export Standard Package
Output capacity :
750L
Input capacity :
1125L
Side Scraper QTY :
1
Color :
Orange/White/Red
Weight :
350kgs
Bottom Scraper QTY :
1
Description

Replaceable Mixing Blades Current Mixer Minimum Maintenance PMC750

Features of Planetary mixer

Planetary mixer is a new type of high efficiency, stirring without dead corner equipment; it has a unique form of stirring. Planet drive the two stirring shaft turns around the material barrel, at the same time, the stirring shaft is high-speed operation, so that the material is strong shearing action, achieve full dispersion and mixing effect. In addition to the equipment within the knife scraping wall around the cylinder axis rotation, will be stuck on the wall material scraping and then put them into mixing shear, that make no residual material in the mixer and mixing effect is more ideal. Cylinder with special seal structure and have the pressure or vacuum stirring. Mixer has good deaeration effect, the cylinder body can be designed to be heated or cooled according to customers' needs. The cover is hydraulic lifting, convenient to operate and clean and the cylinder body can move freely.

APPLICATION INDUSTRIES

1. Concrete
Precast concrete: various block bricks, sleepers, track slabs, metro tunnel segments, PC components, PCCP water pipe,
Lightweight aggregate concrete: Light soil cement slurry,polyphenylene granule cement slurry, other lightweight aggregate concrete,
High Performance ready-mixed concrete: Self-leveling mortar, etc.
2. Ceramics,
3. Pot Clay,
4. Glass Raw Material,
5. Refractories: Unshaped refractories, refractory bricks,
6. Casting materials: Sand mixing, casting coatings,
Others


Principle of Motion: Mixing with no hidden corners in the mixing pan by installing mixing tools and scraper tools on a specially designed drive system.
The mixing track as follows.

750L Current Planetary Cement Mixer Refractory Bricks Sand Mixing 1 Bottom Scraper

Technical Specification
ITEM/(PMC)

PMC
50

PMC
100

PMC
150

PMC
250

PMC
330

PMC
500

PMC
750

PMC
1000

PMC
1250

PMC
1500

PMC
2000

PMC
2500

PMC
3000

PMC 4000
Feeding Capacity (L)7515022537550075011251500187522503000375045006000
Output Capacity (L)501001502503305007501000125015002000250030004000
Feeding Weight (kg)120240360600800120018002400300036004800600072009600
Mixing Power (kw)35.57.5111518.5303745557590110160
Discharging Power (kw)Pneumatic Discharge(Hydraulic Discharge Optional)3334444
Mixing Star*Blade1*21*21*21*21*21*21*32*22*22*23*23*33*33*3
Side Scraper11111111111111
Discharge Scraper--111111112222
Weight (kg)7501000130015002000240039005500600065009200110001200017500
Lifting Power (kw)---3447.511111518.52230-
Dimension (L*W*H) mm

950*
790*
1200

1664*
1453*
1487

1670*
1460*
1620

1860*
1650*
1780

1870*
1870*
1855

2230*
2080*
1880

2580*
2340*
2195

2891*
2602*
2237

3058*
2756*
2395

3223*
2902*
2470

3625*
3230*
2695

3893*
3550*
2875

3893*
3550*
3085

4594*
4150*
3634




750L Current Planetary Cement Mixer Refractory Bricks Sand Mixing 1 Bottom Scraper
