Refractory Materials Concrete Mixing Equipment Concrete Block Mixer Simple Structure
Refractory Materials Concrete Mixing Equipment Concrete Block Mixer Simple Structure
Specifications
Brand Name :
PERMIX
Model Number :
PMC100
Certification :
CE
Place of Origin :
JIAOZHOU CHINA
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
5-10 units per month
Delivery Time :
5-8 days
Packaging Details :
Export Standard Package
Material :
Refractory Materials
Mixing Power :
30kw
Input weight :
180kgs
Blade QTY :
1*3
Color :
Orange/White/Red
Product name :
Planetary Concrete Mixer
Description

Planetary Mixer Lab Usage PMC100 Precast Product Mixing Concrete Panel HeavyDuty

Performance Characteristics:

1) Low Energy Consumption, 30% to 50% reduced comparing same capacity mixers!

2) High Homogenization up to 97-99%!

3) Short Mixing Time as 1-3min!

4) Simple Structure, Simple and Convenient Maintenance

5) Flexible Layout, 1-3 unloading doors are optional for different production lines.

6) Compact Structure and Small Space required

Temperature and moisture sensor

To ensure concrete and prefabricated parts quality, sensors of temperature and moisture made in Bikotronic of German can be selected

Hydraulic Coupling

High Pressure Washing System

Control system

The control system can automatically control the process of dosing, mixing, and discharging.

Spare parts

Spare parts can be supplied at any time.

Technical Data
　 PMC50 PMC
100		 PMC
150		 PMC
250		 PMC
330		 PMC
500		 PMC
750		 PMC
1000		 PMC
1500		 PMC
2000		 PMC
2500		 PMC
3000		 PMC
4000		 PMC
4500
Output capacity(L) 50 100 150 250 330 500 750 1000 1500 2000 2500 3000 4000 4500
Input capacity(L) 75 　 225 375 500 750 1125 1500 2250 3000 3750 4500 6000 6750
Input capacity(kg) 120 　 360 600 800 1200 1800 2400 3600 4800 6000 7200 9600 10800
Diameter of Mixing Tank(mm) 　 　 　 1300 1540 1900 2192 2496 2796 3100 3400 3400 　 　
Mixing Power kw 3 7.5 11 15 18.5 22 30 37 55 75 90 110 160 200
Blade QTY 1/2 1*2 1*2 1*2 1*2 1*2 1*3 2*2 2*2 3*2 3/6 3/9 3/9 3/9
Side Scraper QTY 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Bottom Scraper QTY 1 1 1 1 1 1 1 1 1 1 2 2 2 2
Weight(kg) 700 　 1000 1200 1700 2000 3500 6000 7000 8500 10500 11000 16000 18000

Refractory Materials Concrete Mixing Equipment Concrete Block Mixer Simple Structure
