Large Capacity Industrial Concrete Mixer PMC750 Firebrick Foam Glass Mixing Precast
Large Capacity Industrial Concrete Mixer PMC750 Firebrick Foam Glass Mixing Precast
Specifications
Brand Name :
PERMIX
Model Number :
PMC750
Certification :
CE
Place of Origin :
JIAOZHOU CHINA
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
5-10 units per month
Delivery Time :
30-40 days
Packaging Details :
Export Standard Package
Material :
Steel
Input capacity :
1125L
Input weight :
1800kgs
Mixing Power :
30kw
Blade QTY :
1*3
Color :
Orange/White/Red
Description

Refractory Mixer Planetary Concrete PMC750 Firebrick Foam Glass Mixing Precast

Product advantage and description

Concrete mixer consists of feeding mechanism, mixing mechanism, discharging mechanism, water supply system, electric control system, etc. Plasticity, ductility, briquettability concrete and all kinds of mortar can be mixed.

Concrete mixer is advanced at home and abroad, the ideal model, and has a high degree of automation, high efficiency, low energy consumption, low noise,mixing of good quality, easy operation, fast discharging, long service life of lining and blade, convenient maintenance.
In this machine, the two horizontal mixing shafts are mixed with the reverse equal-speed rotation, which can be realized the maneuvering discharge through the pneumatic piston push rod. Applicable to plasticity, lightweight aggregate concrete ,ductility,and various mortar mixing.
Large Capacity Industrial Concrete Mixer PMC750 Firebrick Foam Glass Mixing Precast
Hydraulic System Maintenance Instruction
1. Strictly follow the instruction to check the condition of the pump before use if the hydraulic pump has stopped for a long time;
2. Check the bolts regularly and assure they are not loosen ;
3. When replace oil, clean oil tank and working components with new oil firstly then pour new oil
4. Replace the oil and oil filter after running the first 100hours, then replace the oil or oil filter after 1000 hours running. From then on, replace oil or oil filter every 2000 hours.

Principle of Motion: Mixing with no hidden corners in the mixing pan by installing mixing tools and scraper tools on a specially designed drive system.
The mixing track as follows.

Large Capacity Industrial Concrete Mixer PMC750 Firebrick Foam Glass Mixing Precast

Technical Specification
ITEM/(PMC)

PMC
50

PMC
100

PMC
150

PMC
250

PMC
330

PMC
500

PMC
750

PMC
1000

PMC
1250

PMC
1500

PMC
2000

PMC
2500

PMC
3000

 PMC 4000
Feeding Capacity (L) 75 150 225 375 500 750 1125 1500 1875 2250 3000 3750 4500 6000
Output Capacity (L) 50 100 150 250 330 500 750 1000 1250 1500 2000 2500 3000 4000
Feeding Weight (kg) 120 240 360 600 800 1200 1800 2400 3000 3600 4800 6000 7200 9600
Mixing Power (kw) 3 5.5 7.5 11 15 18.5 30 37 45 55 75 90 110 160
Discharging Power (kw) Pneumatic Discharge(Hydraulic Discharge Optional) 3 3 3 4 4 4 4
Mixing Star*Blade 1*2 1*2 1*2 1*2 1*2 1*2 1*3 2*2 2*2 2*2 3*2 3*3 3*3 3*3
Side Scraper 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Discharge Scraper - - 1 1 1 1 1 1 1 1 2 2 2 2
Weight (kg) 750 1000 1300 1500 2000 2400 3900 5500 6000 6500 9200 11000 12000 17500
Lifting Power (kw) - - - 3 4 4 7.5 11 11 15 18.5 22 30 -
Dimension (L*W*H) mm

950*
790*
1200

1664*
1453*
1487

1670*
1460*
1620

1860*
1650*
1780

1870*
1870*
1855

2230*
2080*
1880

2580*
2340*
2195

2891*
2602*
2237

3058*
2756*
2395

3223*
2902*
2470

3625*
3230*
2695

3893*
3550*
2875

3893*
3550*
3085

4594*
4150*
3634
