110kw Mixing Power Planetary Concrete Mixer 3000L Output Capacity Low Noise Rotation
110kw Mixing Power Planetary Concrete Mixer 3000L Output Capacity Low Noise Rotation
Specifications
Brand Name :
PERMIX
Model Number :
PMC3000
Certification :
CE
Place of Origin :
JIAOZHOU CHINA
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
5-10 units per month
Delivery Time :
15-18 days
Packaging Details :
Export Standard Package
Output capacity :
3000L
Input capacity :
4500L
Input weight :
7200kgs
Mixing Power :
110kw
Blade QTY :
3*3
Color :
Orange
Description

110kw Mixing Power Planetary Concrete Mixer 3000L Output Capacity

Concrete Other Construction Material Refractory Material Others
Ready-mixed concrete
Precast concrete
Foam concrete
Color concrete
Light concrete
Shotcrete		 Dry mortar
Wet mortar
Gypsum
Aggregate mixing
Emulsified asphalt
Cement adhesive		 Shaped refractory material
Unshaped refractory material		 Glass
Fertilizer
Waste treatment
Mine backfill


Transmission System

The gearbox unit specially designed for a balanced distributor of power to the various mixing device and realize rotation and revolution, ensuring a high efficiency and low noise rotation. The structure is compact, and the deep mixing the internal part of the gearbox will not adhere to the material and increase the cleaning space of the blender.

Maintaining Door

The safety control device ensures that the mixer will not start during maintenance. Large size maintaining door for easy maintenance and cleaning.

110kw Mixing Power Planetary Concrete Mixer 3000L Output Capacity Low Noise Rotation


Technical Specification
ITEM/(PMC)

PMC
50

PMC
100

PMC
150

PMC
250

PMC
330

PMC
500

PMC
750

PMC
1000

PMC
1250

PMC
1500

PMC
2000

PMC
2500

PMC
3000

 PMC 4000
Feeding Capacity (L) 75 150 225 375 500 750 1125 1500 1875 2250 3000 3750 4500 6000
Output Capacity (L) 50 100 150 250 330 500 750 1000 1250 1500 2000 2500 3000 4000
Feeding Weight (kg) 120 240 360 600 800 1200 1800 2400 3000 3600 4800 6000 7200 9600
Mixing Power (kw) 3 5.5 7.5 11 15 18.5 30 37 45 55 75 90 110 132
Discharging Power (kw) Pneumatic Discharge(Hydraulic Discharge Optional) 3 3 3 4 4 4 4
Mixing Star*Blade 1*2 1*2 1*2 1*2 1*2 1*2 1*3 2*2 2*2 2*2 3*2 3*3 3*3 3*3
Side Scraper 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Discharge Scraper - - 1 1 1 1 1 1 1 1 2 2 2 2
Weight (kg) 750 1000 1300 1500 2000 2400 3900 5500 6000 6500 9200 11000 12000 17500
Lifting Power (kw) - - - 3 4 4 7.5 11 11 15 18.5 22 30 -
Dimension (L*W*H) mm

950*
790*
1200

1664*
1453*
1487

1670*
1460*
1620

1860*
1650*
1780

1870*
1870*
1855

2230*
2080*
1880

2580*
2340*
2195

2891*
2602*
2237

3058*
2756*
2395

3223*
2902*
2470

3625*
3230*
2695

3893*
3550*
2875

3893*
3550*
3085

4594*
4150*
3634
