High Speed Planetary Counter Current Mixer PMC500 Type Steel Material Precast
High Speed Planetary Counter Current Mixer PMC500 Type Steel Material Precast
Specifications
Brand Name :
PERMIX
Model Number :
PMC500
Certification :
CE
Place of Origin :
JIAOZHOU CHINA
MOQ :
1 unit
Price :
Negotiation
Supply Ability :
15-20 units per month
Delivery Time :
15-18 days
Packaging Details :
Export Standard Package
Material :
Steel
Input capacity :
750L
Side Scraper QTY :
1
Color :
Orange
Weight :
2400kgs
Bottom Scraper QTY :
1
Description

Counter Current Mixer High Speed Planetary PMC500 Type Steel Material Precast

Features of Planetary mixer
Planetary mixer is a new type of high efficiency, stirring without dead corner equipment; it has a unique form of stirring. Planet drive the two stirring shaft turns around the material barrel, at the same time, the stirring shaft is high-speed operation, so that the material is strong shearing action, achieve full dispersion and mixing effect. In addition to the equipment within the knife scraping wall around the cylinder axis rotation, will be stuck on the wall material scraping and then put them into mixing shear, that make no residual material in the mixer and mixing effect is more ideal. Cylinder with special seal structure and have the pressure or vacuum stirring. Mixer has good deaeration effect, the cylinder body can be designed to be heated or cooled according to customers' needs. The cover is hydraulic lifting, convenient to operate and clean and the cylinder body can move freely.

High Speed Planetary Counter Current Mixer PMC500 Type Steel Material Precast
Principle of Motion: Mixing with no hidden corners in the mixing pan by installing mixing tools and scraper tools on a specially designed drive system.
The mixing track as follows.

High Speed Planetary Counter Current Mixer PMC500 Type Steel Material Precast



Technical Specification
ITEM/(PMC)

PMC
50

PMC
100

PMC
150

PMC
250

PMC
330

PMC
500

PMC
750

PMC
1000

PMC
1250

PMC
1500

PMC
2000

PMC
2500

PMC
3000

 PMC 4000
Feeding Capacity (L) 75 150 225 375 500 750 1125 1500 1875 2250 3000 3750 4500 6000
Output Capacity (L) 50 100 150 250 330 500 750 1000 1250 1500 2000 2500 3000 4000
Feeding Weight (kg) 120 240 360 600 800 1200 1800 2400 3000 3600 4800 6000 7200 9600
Mixing Power (kw) 3 5.5 7.5 11 15 18.5 30 37 45 55 75 90 110 160
Discharging Power (kw) Pneumatic Discharge(Hydraulic Discharge Optional) 3 3 3 4 4 4 4
Mixing Star*Blade 1*2 1*2 1*2 1*2 1*2 1*2 1*3 2*2 2*2 2*2 3*2 3*3 3*3 3*3
Side Scraper 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Discharge Scraper - - 1 1 1 1 1 1 1 1 2 2 2 2
Weight (kg) 750 1000 1300 1500 2000 2400 3900 5500 6000 6500 9200 11000 12000 17500
Lifting Power (kw) - - - 3 4 4 7.5 11 11 15 18.5 22 30 -
Dimension (L*W*H) mm

950*
790*
1200

1664*
1453*
1487

1670*
1460*
1620

1860*
1650*
1780

1870*
1870*
1855

2230*
2080*
1880

2580*
2340*
2195

2891*
2602*
2237

3058*
2756*
2395

3223*
2902*
2470

3625*
3230*
2695

3893*
3550*
2875

3893*
3550*
3085

4594*
4150*
3634


High Speed Planetary Counter Current Mixer PMC500 Type Steel Material Precast
