Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Specifications
Warranty :
1year
Place of Origin :
Chongqing, China
Brand Name :
Umot
Model Number :
42HSC1405/3401/4409/6401-XX
Phase :
2
Type :
Hybrid
Current / Phase :
1A/1A/1.65A/1.5A
Product name :
Linear Stepper Motor
Step angle :
1.8°
Rated current :
1A/1A/1.65A/1.5A
Size :
42x42mm
Motor length :
34/38/40/48mm
Rotor inertia :
35g.cm²/35g.cm²/55g.cm²/150g.cm²
Holding torque :
380/320/400/520mN.m
Resistance :
7/2.2/1.65/3.2Ω
Temperature rise :
80℃
Shape :
Square
MOQ :
5 units
Price :
$33.18/units 5-99 units
Description
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Mini Hybrid Micro Screw Shaft Linear Motion Stepper Motor Nema 17 42mm Linear Lead Screw Stepper Motor
Product name
Linear stepper motor
Warranty
1year
Place of origin
China
Brand name
Umot
Model number
42HSC1405/3401/4409/6401-XX
Phase
2 Phase
Type
Hybrid
Rated current
1A/1A/1.68A/1.5A
Certification
CCC, ce, ISO, RoHS
Step angle
1.8°
Size
42x34/42x38/42x40/42x48mm
Rotor inertia
35g.cm²/35g.cm²/55g.cm²/150g.cm²
Holding torque
380/320/400/520mN.m
Temperature rise
80℃
Shape
Square
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
Hybrid Nema 17 Linear Lead Screw Stepper Motor with 380/320/400/520mN.m Holding Torque
