Specifications
Place of Origin :
China
Brand Name :
Hengquan
Certification :
ISO 9001
Model Number :
EGA30-100 KN
MOQ :
1000m2
Price :
Deliberation
Packaging Details :
packing belt
Delivery Time :
5-8 days
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
40000M2 per week
Material :
Glass Fiber
Hole :
25.4*25.4 mm or 12.7*12.7 mm
Width :
3.95 or 5.95 meters
Length :
100 meters
Feature :
High Tensile
Application :
strengthen of road surface
Description

Rebuild Cement Concrete Road Surface Into Composite Road Surface Glass Fiber Geogrid

Glass Fiber Geogrid Introduction

Glass fiber geogrid is a kind of excellent geosynthetics used for Pavement Reinforcement, old road reinforcement, subgrade reinforcement and soft soil foundation.
It has become an irreplaceable material in the treatment of reflective cracks on asphalt pavement.
The product is a semi-rigid product made of high-strength alkali free glass fiber through advanced warp knitting process and surface coating treatment. It has high tensile strength, low elongation and high temperature resistance, low cold resistance, anti-aging and corrosion resistance. It is widely used in asphalt pavement, cement pavement and roadbed reinforcement, railway subgrade, embankment revetment, airport runway, sand prevention and other engineering projects.

Glass Fiber Geogrid Specification

Technical parameters of glass fiber geogrid
Classification model longitude weft breaking strength (KN/m) elongation at break(%) grid size(mm×mm) width(m)
Glass fiber geogrid GG2525 ≥25 ≥25 ≤3 ≤3 12～50 1～6
GG3030 ≥30 ≥30 ≤3 ≤3 12～50 1～6
GG4040 ≥40 ≥40 ≤3 ≤3 12～50 1～6
GG5050 ≥50 ≥50 ≤3 ≤3 12～50 1～6
GG8080 ≥80 ≥80 ≤3 ≤3 12～50 1～6
GG100100 ≥100 ≥100 ≤3 ≤3 12～50 1～6
GG120120 ≥120 ≥120 ≤3 ≤3 12～50 1～6

Self adhesive glass fiber geogrid		 GGA3030 ≥30 ≥30 ≤3 ≤3 12～50 1～6
GGA4040 ≥40 ≥40 ≤3 ≤3 12～50 1～6
GGA5050 ≥50 ≥50 ≤3 ≤3 12～50 1～6
GGA8080 ≥80 ≥80 ≤3 ≤3 12～50 1～6
GGA100100 ≥100 ≥100 ≤3 ≤3 12～50 1～6
GGA120120 ≥120 ≥120 ≤3 ≤3 12～50 1～

Glass Fiber Geogrid Features:

(1)High tensile strength in warp and weft directions;

(2)Low elongation;

(3)Excellent temperature range;

(4)Good anti-age and alkali-resistance;

(5)Reduce construction cost, extend service life of road and prevent deflection cracks.

Glass Fiber Geogrid Application:

1,Reinforce weak soil foundations,

2,Reinforce the embankment dam and the retaining wall,
3,Strengthen rivers and seawalls,

4,Disposal of landfill,

5,Roadbed enhancement of highways,

6,railways and airports,
