Specifications
Place of Origin :
China
Brand Name :
Hengquan
Certification :
ISO 9001
Model Number :
TGSG15,TGSG20,TGSG25,TGSG30,TGSG35,TGSG40,TGSG45,TGSG50
MOQ :
1000m2
Price :
Deliberation
Packaging Details :
packing belt
Delivery Time :
5-8 days
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
40000M2 per week
Type :
biaxial plastic geogrid and uniaxial plastic geogrid
Material :
polypropylene or polyethylene
Mesh hole :
32*32mm
Tensile Strength :
TGSG30-30KN
color :
black
width :
2m 0r 3m 0r 4m
length :
50 m or 100 m
Application :
Subgrade Stabilization
Description

Highway Road Construction Gravel Driveway Subgrade Stabilization Plastic Geogrid Mesh

Plastic Geogrid Mesh Introduction

Plastic geogrid is mainly manufactured from polypropylene or high density polyethylene, which are all UV stabilized, chemical and biological resistance. The plastic geogrid is mainly used in the construction of roadways, highways, railways, slopes for ground stabilization and subgrade reinforcement. The plastic geogrid is extruded into sheet and then punched into regular mesh pattern and finally stretched. According to the stretched direction, it can be divided into uniaxial plastic geogrid and biaxial plastic geogrid.

Plastic Geogrid Mesh Features

High tensile strength in both longitudinal and transverse directions.

Convenient to use and reduce the construction cost.

Increase the bearing capacity of the subgrade.

Reduce the soil erosion.

UV stabilized.

Resistance to the chemical and biological corrosion.

Biaxial Plastic Geogrid Specification

project TGSG15-15 TGSG20-20 TGSG25-25 TGSG30-30 TGSG40-40 TGSG45-45 TGSG50-50
Longitudinal tensile yield force KN/m 15 20 25 30 40 45 50
Transverse tensile yield force KN/m 15 20 25 30 40 45 50
Tensile Strength @2% Strain KN/m 5 7 9 10.5 14 16 17.5
Tensile Strength @5% Strain KN/m 7 14 17 21 28 32 35
Roll width 3.95 or 5.95 meters
Roll Length 50 meters

Plastic Biaxial Geogrid Applications

Plastic biaxial geogrid is the ideal geotechnical material in situations where stresses are applied in two directions, it is the ideal geotechnical product used to reinforce the pavement base and improve the subgrade for any soil stabilization and reinforcement applications such as municipal roads, highways railway, access roads, parking lots industrial shipping yards, etc. provides high strength, high performance, longer life, ensured reliability and quick installation for base reinforcement of paved roads, construction haul roads, foundation reinforcement, permanent unpaved roads, working platforms on weak soils, parking areas, etc

30KN 50m Plastic Geogrid Mesh For For Ground Stabilization

30KN 50m Plastic Geogrid Mesh For For Ground Stabilization
