Energy Efficiency Plastic Zipper Injection Molding Machine With Servo Motor
Energy Efficiency Plastic Zipper Injection Molding Machine With Servo Motor
Specifications
Brand Name :
GS
Model Number :
GS608V
Place of Origin :
Shanghai, China (Mainland)
Certification :
ISO9001
Price :
Negotiable
MOQ :
1 Set/Sets
Condition :
New
Automatic :
Yes
Injection Weight :
2721g
Injection Rate :
700g/s
Clamping Force :
6080kN
Opening Stroke :
900mm
Power(W) :
44.3kW
capability :
save much more energy
Description

Plastic Zipper Injection Molding Machine

GSV608
A
B
C

INJECTION UNIT
Screw Diameter
mm
80
85
90
Screw L/D Ratio
L/D
23.4

22
20.8
Shot size(Theoretical)
cm3
1959
2210
2480
PS) Injection Weight
g
1783
2011
2256
PS Injection Rate
g/s
446
502
560
PS Plasticizing capacity
g/s
70
85
110
Injection Pressure
Mpa
201
178
159
Screw stroke
mm
390
Screw Speed
rpm
0-130

CLAMPING UNIT
Clamp Tonnage
KN
530
Toggle stroke
mm
830
Space Between Tie Bars
mm
840*840
Max.Mold Height
mm
830
Min.Mold height
mm
350
Ejector stroke
mm
250
Ejector tonnage
KN
160
Ejctor Numbre
peicc
13

OTHERS
Max.Pump Pressure
Mpa
16
Pump Motor Power
KW
55
Heater Power
KW
32
PS Hopper Capacity
Kg
150
Oil Tank Capacity
L
1300
Machine Dimension(L*W*H)
m
9*2.56*3.5
Machine Weight
t
30

Advantage:

Large Injection Molding Machine Series Servo-motor Energy Saving & Precision Injection Moulding Machinery

The machine using high-performance servo dynamic control system and the gear pump as the power source. With characteristics as high-response, high energy-saving, high control precision and lower noise, make the electrical servo motor and the hydraulic technology perfect connection.

Machine Feature:

1 Enhanced clamping mechanism to meet requirements for efficient production.

2 Excellent clamping features with optimized linkage mechanism to have faster and smooth operation.

3 Professional plasticizing unit is applicable for production of various raw materials, and to improve plasticize performance significantly.

4 Excellent injection performance with twin-cylinder injection mode, have more reliable and stable performance.

5 Professional platen optimization, the platen after finite element analysis and optimization has high rigidity and strength.

6 Centralized lubrication system with reliable protective configuration, quantitative distribution and centered lubrication, provide more professional lubrication protection and extend mechanical life.

7 New frame type structure, simple and clean appearance, with more reasonable stress on machine body and high rigidity.

Our Services:

Pre-Sale Service
1. Act a good adviser and assistant of clients enable them to get rich and returns on their investments.
2. Select correct and suitable equipment model
3. Design and make products according to clients’ special requests
On-Sale Service
1. Reporting on machine situation from time to time.
2. Pre-check and accept products ahead of delivery
3. Drawing workshop layout 4. Train the first-line operators
After-Sale Service
1. Provide considerable services to minimize client’s worries.
2. Assist clients to prepare for the first construction schedule.
3. Install and debug the equipment
4. Examine the equipment
5. Take initiative to eliminate the troubles rapidly
6. Provide perfect service
