Small Variable Pump Injection Molding Machine 100T Low Energy Consumption
Small Variable Pump Injection Molding Machine 100T Low Energy Consumption
Specifications
Brand Name :
GS
Model Number :
GS98V
Place of Origin :
Shanghai, China (Mainland)
Certification :
ISO9001
Price :
Negotiable
MOQ :
1 Set/Sets
Plastic Type :
Thermoplastic
Injection Weight :
160.2g
Injection Rate :
108.3g/s
Clamping Force :
980kN
Opening Stroke :
320mm
Power(W) :
6.5kW
After-sales Service Provided :
Engineers available to service machinery overseas
capability :
save much more energy
Description

100T Miniature Injection Plastic Machine

GS98V

A

B

C


INJECTIONUNIT

Screw Diameter

mm

32

36

40

Screw L/D Ratio

L/D

22.5

20

18

Shot size(Theoretical)

cm3

121

153

188

PS) Injection Weight

g

110

139

171

PS Injection Rate

g/s

66

84

104

PS Plasticizing capacity

g/s

9.9

11.3

13.9

Injection Pressure

Mpa

237

188

152

Screw Speed

Rpm

0-205


CLAMPINGUNIT

Clamp Tonnage

KN

900

Toggle stroke

mm

320

Space Between Tie Bars

mm

360*360

Max.Mold Height

mm

380

Min.Mold height

mm

150

Ejector stroke

mm

100

Ejector tonnage

KN

33

Ejector Number

piece

5


OTHERS

Max.Pump Pressure

Mpa

17.5

pump motor power

KW

7.5

Heater Power

KW

6.2

Machine Dimension(L*W*H)

m

4.32*1.2*1.86

Machine Weight

t

3.46

PS Hopper Capacity

Kg

25

Oil Tank Capacity

L

240

Main Features:

● After preform injection, the heat is used for bottle blowing, no need of preform packaging, storage, reh- eating and other working procedures.

● Less land occupation, simple management, high degree of automation, less labor intensify (1 person can control more than 3 machines).

● With a temperature adjustable station, suitable for complicated shape, difficult forming products (such as PP IV-solution bottles).

● The compact structure greatly shortens the production cycle and enhances productivity.

● Adopt variable pump and servo motor, maximally reduce energy consumption.

● The replacement of the mold cost is far lower than similar foreign equipment.

FAQ:

Q1: Are you a trading company or a manufactory?

A1: We are a manufactory, we supply the factory price with good quality, welcome to visit !

Q2: What’s your guarantee or the warranty of the quality if we buy your machines?

A2: We offer you high quality machines with 1 year guarantee and supply life-long technical support.

Q3: When can I get my machine after I paid?

A3: The delivet time is based on the exact machine you confirmed.

Q4: How can I install my machine when it arrives?

A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines.

Q5: How about the spare parts?

A5: After we deal down all the things , we will offer you a spare parts list for your reference.
