Energy Saving Two Color Injection Molding Machine 250 Ton 22KW Power
Energy Saving Two Color Injection Molding Machine 250 Ton 22KW Power
Specifications
Brand Name :
GS
Model Number :
GS258V
Place of Origin :
Shanghai, China (Mainland)
Certification :
ISO9001
Price :
Negotiable
MOQ :
1 Set/Sets
Type :
Preform Injection
Injection Weight :
649g
Injection Rate :
181g/s
Clamping Force :
2580kN
Opening Stroke :
540mm
economic benefits :
obvious--30-50% electricity can be saved
Power(W) :
22KW
Description

Plastic Injection Moulding Machine 250 ton
GSV SERIVES able to save 30%-50% electric power consumption base onVariable Pump.
Specification:

GS258V
A B C
INJECTION UNIT Screw Diameter mm 50 55 60
Screw L/D Ratio L/D 22 20 18.3
Shot Size(Theoretical) cm3 471 570 679
Injection Weight g 429 519 618
Injection Rate g/s 145 175 209
Plasticizing Capacity g/s 21.6 26.6 30.3
Injection Pressure Mpa 215 178 149
Screw Speed rpm 0-160
CLAMPING UNIT Clamp Tonnage KN 2500
Toggle Stroke mm 540
Space Between Tie Bars mm 580*580
Max.Mould Height mm 580
Min.Mould Height mm 220
Ejector Stroke mm 150
Ejector Tonnage KN 62
Ejector Number piece 9
OTHERS Max.Pump Pressure Mpa 16
Pump motor Power KW 22
Heater Power KW 16.65
Machine Dimension(L*W*H) m 6.09*1.55*2.09
Machine Weight t 8.3
Hopper Capacity Kg 50
Oil Tank Capacity L 555

Product features:

Adopting Europe technology , hydraulic unit adopts proportional pressure and flow control ,the pressure and the speed can be adjusted , stable movement curve and gentle shock ,the computer is imported from Industry family. The LCD displaying screen with high clarity has Chinese and English language to use. Close-loop PID temperature control with the advantage of high precision. The operating table of the injection molding machine have two safety, one is machine safety, another is electrical safety, that ensures the operators ’s safety.

1. Close-loop control for injection,plasticizing,pressure maintaining and back-pressure.sevro motor direct drive.

2. Be able to do the process of feeding material and opening mold at the same time, to save much more cycle time of molding.

3. Speed from 0 to 500mm/s need only 35 millisecond. Super high speed response with high speed injection, accurate measurement of stocke control,it can achieve thin moring.

4. Adopt anti-interference number force transducer to achieve high precision control.

5. Central symmstric two moving oil cylinder to get balanced force for nozzle,It's more reliable sealing.

Machine FAQ

1. The machine is in running condition, and can make products?

Sure, machine must be in running condition, and take machines back, can make goods directlry.

2. Is there any warranty?

Of course, within three months, machine is with problem. offer free components.

3. Is there any oversea service?

If keep our engineers safety abroad, engineer will go oversea to help clients deal with problems.

4. Don't know how to set the production parameter of the controller?

Will take video to show how to do it.

5. How to confirm the machine auxilaries?

We'lll advise every auxilary machine capacity based on machine capacity and the environment of clients' country

6. Other detail problem with machine and production.

Let's discuss further.
