High Speed. Plastic Broom Handle Making Machine Two Shot Molding Process
High Speed. Plastic Broom Handle Making Machine Two Shot Molding Process
Specifications
Brand Name :
GS
Model Number :
GS128V
Place of Origin :
Shanghai, China (Mainland)
Certification :
ISO9001
Price :
Negotiable
MOQ :
1 Set/Sets
Style :
Horizontal
Plastic Type :
Thermoplastic
Injection Weight :
282g
Injection Rate :
123g/s
Clamping Force :
1280kN
Opening Stroke :
360mm
colour :
red and blue
features :
high-speed.precision,energy-saving,safety and reliability
Description

Plastic Broom Handle Making Machine

GS128V

A

B

C


INJECTIONUNIT

Screw Diameter

mm

36

40

45

Screw L/D Ratio

L/D

23.3

21

18.7

Shot size(Theoretical)

cm3

173

214

270

PS) Injection Weight

g

157

195

246

PS Injection Rate

g/s

83

102

130

PS Plasticizing capacity

g/s

11.3

13.9

18

Injection Pressure

Mpa

231

188

148

Screw Speed

Rpm

0-180


CLAMPINGUNIT

Clamp Tonnage

KN

1280

Toggle stroke

mm

360

Space Between Tie Bars

mm

410*410

Max.Mold Height

mm

450

Min.Mold height

mm

150

Ejector stroke

mm

120

Ejector tonnage

KN

33

Ejector Number

piece

5


OTHERS

Max.Pump Pressure

Mpa

17.5

pump motor power

KW

11

Heater Power

KW

9.75

Machine Dimension(L*W*H)

m

4.85*1.27*1.96

Machine Weight

t

4.6

PS Hopper Capacity

Kg

25

Oil Tank Capacity

L

280

Reliable Features

* Screw of big length to diameter ratio, uniform plastication and high plasticizing capability

* Multi Step adjustment of injection speed or pressure

* Back pressure control of molten plastic

* Double toggle mold closing system with a large force magnification ratio and a large stroke ratio

* Very good speed characteristic of high speed mold closing and low pressure mold protection

* Various kinds of hydraulic ejectors

* Double proportional, load sensitive hydraulic circuit

* For big sizes of machines there are several oil pumps in a group, use proportional valve to compensate the difference of pressure or flow between pumps

* Triple interlock of mechanic, electric and hydraulic devices

* Hydraulic knockout core device and rotary mold-parting the work piece device

* Using the computer, electric and hydraulic elements of famous brands in the world

Machine FAQ

1. The machine is in running condition, and can make products?

Sure, machine must be in running condition, and take machines back, can make goods directlry.

2. Is there any warranty?

Of course, within three months, machine is with problem. offer free components.

3. Is there any oversea service?

If keep our engineers safety abroad, engineer will go oversea to help clients deal with problems.

4. Don't know how to set the production parameter of the controller?

Will take video to show how to do it.

5. How to confirm the machine auxilaries?

We'lll advise every auxilary machine capacity based on machine capacity and the environment of clients' country

6. Other detail problem with machine and production.

Let's discuss further.
