High Precision Two Color Injection Molding Machine For Making Plastic Utensils 160T
High Precision Two Color Injection Molding Machine For Making Plastic Utensils 160T
Specifications
Brand Name :
GS
Model Number :
GS168V
Place of Origin :
Shanghai, China (Mainland)
Certification :
ISO9001
Price :
Negotiable
MOQ :
1 Set/Sets
technical requirement :
fully meeting the exporting European countrise
economic benefits :
obvious--30-50% electricity can be saved
Automatic :
Yes
Injection Weight :
326g
Injection Rate :
136.3g/s
Clamping Force :
1680kN
Opening Stroke :
430mm
Power(W) :
10kW
Description

Machines for Production of Plastic Utensils 160T

GS168V

A

B

C


INJECTIONUNIT

Screw Diameter

mm

40

45

50

Screw L/D Ratio

L/D

22.5

20

18

Shot size(Theoretical)

cm3

253

320

395

PS) Injection Weight

g

230

291

359

PS Injection Rate

g/s

100

126

156

PS Plasticizing capacity

g/s

13.9

18

21.6

Injection Pressure

Mpa

240

190

154

Screw Speed

Rpm

0-195


CLAMPINGUNIT

Clamp Tonnage

KN

1600

Toggle stroke

mm

430

Space Between Tie Bars

mm

470*470

Max.Mold Height

mm

520

Min.Mold height

mm

180

Ejector stroke

mm

140

Ejector tonnage

KN

33

Ejector Number

piece

5


OTHERS

Max.Pump Pressure

Mpa

17.5

pump motor power

KW

15

Heater Power

KW

9.75

Machine Dimension(L*W*H)

m

4.9*1.29*1.96

Machine Weight

t

5.3

PS Hopper Capacity

Kg

25

Oil Tank Capacity

L

350

Two Color Injection Molding Machine

Features of injection molding machine for making plastic bowls / plates / cups / spoons :

1) LCD computer control with big display screen
2) Hydraulic double proportional valve
3) Hard chrome plated high tensile strength steel tie bars
4) Generous space for fitting large moulds
5) Large opening stroke
6) Two position transducers to control Clamping and Injection
7) Four stages of injecting, independent velocity and pressure control
8) Hydraulic mould height adjustment device
9) Screw cold-start prevention device
10) Melt decompression control
11) Screw back pressure control
12) Multiple hydraulic ejection
13) Differential high speed clamping
14) Centralized lubrication system
15) Low pressure mould protection device
16) Mechanical safety interlock
17) Double electrical safety interlock
18) Oil return filter
19) Oil tank with inner stainless steel container

Our service:

• Your inquiry related to our product & price will be replied within 24hours

• Well-trained & experienced staff are to answer all your inquiries in English and Chinese

• Working time: 8:30am ~6:00pm, Monday to Friday(UTC+8).

• OEM & ODM projects are both available

• Your business relationship with us will be confidential to any third party.

• Good after-sale service offered, please get back to us if you got any questions.
