Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw
Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw
Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw
Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw
Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw
Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw
Specifications
Brand Name :
Yongjie
Model Number :
SJSL65
Certification :
CE
Place of Origin :
China
MOQ :
1sets
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200sets per year
Delivery Time :
35-50 days
Packaging Details :
sea worthy film ( or wooden box per requirements)
Screw design :
twin screw extruder
Application :
plastic pellets
Warranty :
one year
Overseas engineers :
Available for installation and Comissioning
Screw diameter :
62.4mm
Motor :
90kw
Belt length :
18M or customized
Capacity :
300-450 kg/h
Description

Corn Starch Biodegradable PLA PE PP Plastic Pellets Machine Filler Masterbatch Machine

Quick details

Power:90kw option according to required output

Screw diameter:62.4mm

Barrel diameter: 63mm

L/D:44/48

Output:300-450kg/h according to different material, formula and technology of process etc.

Cutting way: air cooling belt for biodegradable corn startch, PLA, also underwater and water strand for PLA according to different recipe of PLA.

Warranty:one year

Lead time:45 days after deposit

Scope of supply

No. Contents Unit Quantity Marks
1 High speed mixer set 1 500L
2 Screw feeder machine set 1 2.2kw
3 Twin screw extrusion system set 1
3.1 Feeding system set 1 1.5kw
3.2 SJ-75B Twin screw extruder set 1 132kw, 48:1
3.3 Vacuum venting system set 1 2.2kw
3.4 Water cycling system set 1 0.55kw
3.5 Automatic screen changer set 1 1.5kw
4 Electric cabinet set 1
5 Air cooling strand auxiliary machine set 1
5.1 Die head set 1
5.2 Conveyer belt 18M set 1
5.3 Pelletizer set 1
5.4 Vibrator set 1
5.5 Cooling production bin set 1
6 Documents set 1


Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw

Corn Starch Biodegradable Plastic Pellet Making Machine , PP Extruder Machine 90kw

Main technical data of various model of twin screw extruder pelleitizing machine

Model type Series Barrel Diameter (mm) Screw Diameter (mm) Screw L/D screw speed n(r/min) Main motor power(Kw) Screw torque T(N.m) Torque rating (T/A3) Typical production capacity (kg/h)
SJSL-36 A/B/C/D 36 35.6 32-48 400/600 11/15/18.5/22 125-225 4.6-8.3 30-120
SJSL-51 A/B/C/D 51 50.5 32-52 500/600 45/55/75/90 405-680 5.1-8.5 120-400
SJSL-65 A/B/C/D 63 62.4 32-64 500/600 75/90/110/132 680-1200 4.8-8.5 180-750
SJSL-75 A/B/C/D 72 71 32-64 500/600 110/132/160/250 995-1890 4.6-8.7 300-1200
SJSL-95 A/B/C/D 94 93 32-64 500/600 250/315/450/550 2260-4510 4.7-8.7 700-2500
SJSL-135 A/B/C/D 135 133 32-48 400/500 550/750/900/1200 6200-10800 4.4-7.7 1550-6500

Company Brief

Nanjing Yongjie Qixin Machinery Equipment Co.,Ltd Founded in 2001, covers an area of 20,000 square meters on our own land, with monthly output of machine 20sets. Our factory is certificated to CE, ISO9001:2008.The company concentrates on research, development and production of “high level, accurate, highly sophisticated series product parallel co-rotating “cordwood” twin screw extruder, single screw extruder, two stage extruders and automatic plastic pelletizing machines. We have provided customers first-class products with “strong torque, high production, energy conservation and environmental protection products. The special designed screw structure has realized successfully for “one step shaping” on many
