PVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing Quality
PVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing Quality
PVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing Quality
PVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing Quality
PVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing Quality
PVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing Quality
Specifications
Brand Name :
HB
Model Number :
SMW-500
Certification :
CE ISO9001:2008
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10 Sets per Month
Delivery Time :
20-30 working days
Packaging Details :
Wrapping Film
Motor :
37kw
One set Capacity :
120-300kg/h
Material Applied :
PVC Pipe
Powder Size :
10-80 mesh
Sieving Method :
Vibrating Sieving
Dust Collection :
16 Bags
Pulverizer sets :
Double
Line sets :
2 sets
Description

Pipe PVC Pulverizer Machine Crushed PVC Pipes Pulverizing Mill

We have absorbed the advanced technology at home and abroad to develop the Good quality excellent price hot plastic and rice mill milling machine, which is applicable to the powder processing of PVC plastic (Low to moderate hardness), PVC profile, PVC board scraps .Usually, the capacity for SMW500 pipe PVC pulverizer machine is 200 kg / h (30 mesh). Some may doubt it, why do they need the powder form, it seems make the production progress more complex and add the cost. However, that was not the case.

The Reasons of Using a Pulverizer

Increase Profits

  • Reuse of material
  • Reduce wastage
  • Reduce cost

Enhance product quality

  • Smooth product quality
  • Uniform wall thickness
  • Free-flowing powder

Improve particle size distribution

  • Smooth product surface
  • Better coating quality

Enhance mixing possibility

  • Increase flow rate
  • Enhance adhesion to mixture
  • Improve homogeneous material powder mixing quality

Main Technical Parameters

Type Main Motor(KW) Total Power(KW) Weight(KG) Capacity(KG/H) /SET
SMW-500

37

 43 1680 120-300
SMW-600 45/55 52/62 2280 180-480
SMW-800 75 88 2880 320-880

Specifications are not binding and subject to change without notice.

Characteristics of Pulverizer

  1. Save labour cost, one employee can inspecting 5 sets at a time
  2. Compared with similar grinders, its output is greatly improved (increased by 20%-50%) under the same power.
  3. It is energy-saving.
  4. The dust collector is added to effectively reduce dust pollution, We also provide pulse dust collector
  5. The discharging of the main fan reduces labor intensity of operating workers.
  6. The door cover of the host can be opened for convenience of cutters.
  7. Wind and water cooling system are adopted to decrease the working temperature inside the machine body

PVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing QualityPVC Pipe PVC Pulverizer Machine Crushed Improve Homogeneous Powder Mixing Quality

RFQ

There are a number of important factors that have to be considered when choosing the best suited Huibang size reduction unit for your particular application. To ensure that the system we recommend offers the best specification, we ask that you fill out this form and answer the following questions:

NO. ITEMS
1

Type of Plastic: MFI (Melt Flow Index)
2

Size of regrind to be fed into the pulverizer:
3

Machine currently using to make regrind?
4

What process:(eg. Extrusion, blow molding, etc.)
5

Size of powder desired:
6

Mesh/Micron size
7

Required throughputs per hour:
8

Any special characteristics to your particular material:(eg. Additives etc.)
