Multi Station Automatic Thermoforming Machine For Making Take Away Food Container
Multi Station Automatic Thermoforming Machine For Making Take Away Food Container
Multi Station Automatic Thermoforming Machine For Making Take Away Food Container
Multi Station Automatic Thermoforming Machine For Making Take Away Food Container
Specifications
Brand Name :
ALLEPACK
Model Number :
XG-A
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
USD140000/Set
Delivery Time :
35 days
Packaging Details :
Standard Export Packing+BOPP streching film
automaticity :
full-automatic
mold :
forming mold and cutting mold
Product Type :
plastic thermoforming machine
Max Forming Area :
600*760mm
Max Forming Depth :
140mm
Sheet Thickness :
0.2-2.0mm
Sheet Material :
PP, BOPS, PE, PVC, Pet, ABS, HIPS, EPS etc.
Pressure :
Negative and positive
Cutting Pressure :
100ton
Max.Cutting Length :
1500mm
Origin :
shanghai
Description

Multi Station Automatic Thermoforming Machine For Making Take Away Food Container

Multi station Thermoforming Machinery for Making Take Away Food Container are designed and manufactured by our company, It absorbs the most advanced thermoforming technology from Germany, this full automatic production line combines sheet roll feeding, forming,cutting,stacking,conveying compleated on one machine. The whole system is fully-automatic and controlled by PLC through a touching screen. This machine is wide used in plastic containers/boxes/trays/bowls producing field.

Multi Station Automatic Thermoforming Machine For Making Take Away Food Container

Technical parameters

Model XG-A-3
Power supply 380V 50/60Hz
Total Power 160 kw
Actual electrical consumption 20-60kw/H
Heating Oven with preheating Length of 1800mm,width of 800mm
Suitable sheet width 350-800mm
Max forming area 600*760mm
Min. forming area 350*410mm
Max forming depth 150mm
Maximum cutting force 100Ton
Output capacity 10-35cycles/min
Forming mold stroke 2x150mm
Cutting mold stroke 2x150mm
Parallel precision ofcutting table ±0.02MM
Precision of sheet pulling ±0.05MM
Cutting accuracy ±0.05MM
Suitable material PP PE PVC PS PETPS Foam(biodegraded material)etc.
Product thickness 0.15-2.0mm
Dimension 11000*2200*2500mm
Weight

12Tons without mold

Packing and shipping:

Multi Station Automatic Thermoforming Machine For Making Take Away Food Container

Application:

This thermoforming machine used for producting high demand of disposable fresh/fast food,fruit plastic cups,boxex,plates,container,and pharmaceutical,wine,electrical blister packaging,PP,PS,PET,PVC,OPS plastic sheet etc.

Multi Station Automatic Thermoforming Machine For Making Take Away Food Container
