PLC Servo Motor Stretching Thermoforming Machine
PLC Servo Motor Stretching Thermoforming Machine
Specifications
Brand Name :
ALLEPACK
Model Number :
XG-D
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
2set/month
Delivery Time :
20 days
Packaging Details :
Standard Export Packing+BOPP streching film
Sheet Material :
PP, BOPS, PE, PVC, Pet, ABS, HIPS, EPS etc.
sheet width(max) :
810mm
forming speed :
20-25cycles/min
automaiton type ength :
servo drive
Weight :
4500kg
type :
new
Product name :
servo motor plastic thermoforming machine
Warranty :
2 year
quality :
100% Strictly Tested, 100%Brand
Description

Fully automatic PLC servo motor Stretching thermoforming machine/forming machine , XG-D thermoforming machine adopts the most advanced plastic vacuum thermoforming technology. Automatic operations allow for less labor intensive work flow while producing consistent product. Combining heating, forming& trimming all into a single unit. AC driven Servo Motor serves purpose for environmental regulations,low maintenance operation,and producing precision final product. Operation is controlled by PLC advanced intelligence computer which enables the ease of operation,employee safety&maximum production output.

Model
APL- 2078
Max. Forming Area
600 * 700 mm
Cut type
Cutting in mould/Forming and Cutting Separate
Max. Forming Height(depth)
180 mm
Sheet Thickness
0.1-2.0 mm
Max. reel Dia
1000 mm
Air Pressure
0.7 Mpa
Air Consumption
5000 (Liters/min)
Water Consumption
170 (Liters/min)
Production Speed
15–40 Mold/ Minute PVC, PP , PET , PS
Power Supply
380V - 50HZ - 3 PH
Total Power
90 KW (Normally use 36-50 KW)
Weight
12000 Kg (For reference only.)
Measurement(L*W*H)
12500 * 2300 * 2600 mm

PLC Servo Motor Stretching Thermoforming Machine

Our Advantages and Why Choose US
1. Professional We have been dealing with vacuum forming machine for over 15 years.
2. Responsible There are 5 experienced after service engineers in our team. Provide life long maintenance service for customers all over the world
3. Exporting ability is our factor with rich experience to help our customer import equipment to their country
