Automatic Stretching Thermoforming Machine
Automatic Stretching Thermoforming Machine
Specifications
Brand Name :
ALLEPACK
Model Number :
XG-D
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T,L/C
Supply Ability :
2set/month
Delivery Time :
20 days
Packaging Details :
Standard Export Packing+BOPP streching film
Sheet Material :
PP, BOPS, PE, PVC, Pet, ABS, HIPS, EPS etc.
sheet width(max) :
810mm
forming speed :
20-25cycles/min
automaiton type ength :
servo drive
Weight :
4500kg
type :
new
Product name :
servo motor plastic thermoforming machine
Warranty :
2 year
quality :
100% Strictly Tested, 100%Brand
Description

Fully automatic PLC servo motor Stretching thermoforming machine/forming machine , XG-D thermoforming machine adopts the most advanced plastic vacuum thermoforming technology. Automatic operations allow for less labor intensive work flow while producing consistent product. Combining heating, forming& trimming all into a single unit. AC driven Servo Motor serves purpose for environmental regulations,low maintenance operation,and producing precision final product. Operation is controlled by PLC advanced intelligence computer which enables the ease of operation,employee safety&maximum production output.

SPECIFICATIONS FOR SERVO MOTOR THERMOFORMING MACHINE
Model
TTF-520AF
Max. Forming Area
520mm×400mm
Max. Forming Depth
100mm
Max. Forming Speed
30 times/min
Max. Sheet Width
570mm
Sheet Thickness
0.3-1.8mm
Suitable Sheet
PP/PS/HIPS/PET/PVC/EPS Foam etc.
Air Pressure
0.6-0.8Mpa
Air Consumption
3m³/min
Water Consumption
0.7m³/min
Rated Power
110kw
Power Supply
AC380V, 50Hz Three-phase and Four-wire
Procedure
Forming-Punching-Cutting-Stacking
Dimension
L11000×W4600×H2700mm
Weight
About 11.0T

Automatic Stretching Thermoforming Machine

Our Advantages and Why Choose US
1. Professional We have been dealing with vacuum forming machine for over 15 years.
2. Responsible There are 5 experienced after service engineers in our team. Provide life long maintenance service for customers all over the world
3. Exporting ability is our factor with rich experience to help our customer import equipment to their country

Automatic Stretching Thermoforming Machine
