500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
Specifications
Model NO. :
300/600
Warranty :
5 Years
Transport Package :
Shrink Film
Specification :
300/600
Trademark :
CHANGYUE
Origin :
Qingdao, China
HS Code :
84778000
Supply Ability :
200-300Kg/H
Package Size :
400.00cm * 200.00cm * 250.00cm
Package Gross Weight :
2500.000kg
After-sales Service :
Site Installation
Automatic Grade :
Full-Automatic
Structure :
Vertical
Customization :
Available | Customized Request
Shipping Cost :
about shipping cost and estimated delivery time.
  :
Initial Payment Full Payment
Currency :
US$
Return&refunds :
You can apply for a refund up to 30 days after receipt of the products.
Place of Origin :
Shandong, China
Brand Name :
Changyue
Packaging Details :
Export Film Packing / According To Customer
Delivery Time :
15 Days (1 - 1 Pieces) To Be Negotiated ( > 1 Pieces)
Description

High Speed Hot Cold Mixer for Plastic PVC Powder Vertical Structure PVC Mixing Machine

Product Description

SRLSeries powder mixer for plastic extruder units are widely used for mixing, drying, and coloring for all kinds of plastic resin such as PVC , PE, PP. They can also be applied in drying of engineering plastic such as, ABS, PC, etc. This unit is composed of heating and cooling mixers. Hot material from heating mixer is fed into cooling mixer for cooling to eliminate gas and avoid burning.
Main Technical Parameter
Model SRL-Z100/200 SRL-Z200/500 SRL-Z300/600 SRL-Z500/1250 SRL-Z800/1600
Total volume (L) 100/200 200/500 300/600 500/1250 800/1600
Effective capacity (L) 65/130 150/320 225/380 330/750 600/1050
Stirring speed (rpm) 650/1300/200 475/950/130 475/950/100 430/860/70 370/740/50
MIxing time (min.) 8-12 8-12 8-12 8-12 8-12
Motor power (kw) 14/22/7.5 30/42/11 40/55/11 55/75/15 83/110/22
Ovarall dimension (mm) 1950*1600*1800 4580*2240*2470 4800*2640*2480 5600&3000*3100 5170*3200*4480
Weight (kg) 2200 3400 3600 6500 9800
Output (kg/h) 165 330 495 825 1320
Detailed Photos
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
500/1250 800/1600 PVC Powder Mixer 200-300Kg/H PVC Mixing Machine
