900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
Specifications
Certification :
ISO9001
Model NO. :
65/33
Engagement System :
Full Intermeshing
Screw Channel Structure :
Deep Screw
Exhaust :
Exhaust
Automation :
Automatic
Computerized :
Computerized
Transport Package :
Film
Specification :
20-63mm
Trademark :
HYD
Origin :
Shandong, China
Type :
Pipe Extruder
Plastic Processed :
PE
Product Type :
Extrusion Molding Machine
Feeding Mode :
One Feed
Assembly Structure :
Separate Type Extruder
Screw :
Single-Screw
Customization :
Available | Customized Request
Place of Origin :
Shandong, China
Brand Name :
Changyue
Packaging Details :
Export Film Packing / According To Customer
Delivery Time :
15 Days (1 - 1 Pieces) To Be Negotiated ( > 1 Pieces)
Description

Full Intermeshing Engagement System 65/33 HDPE Pipe Extrusion Machine for Output

HDPE pipe production line

Prouduct description
PE pipe extrusion machine is mainly used for producing agricultural irrigation pipes,drainage pipes,gas pipes,water supplying pipes,cable conduit pipes etc. The pipe has some excellent features such as heating resistant,etc. our extrusion line is designed with high efficiency extruder and equipped with reducer which is high speed and low noise,Gravimetric dosing unit and ultrasonic thickness indicator can be assembled according to customer's demand to ascend the priecise of the pipes.Turn key solution can be provided, like laser printer , crusher,shredder, water chiller,air compressor etc. to achieve high-grade and automatic tube production.

Process Flow:
Raw material+master batches-Mixing-Vacuum feeder-Plastic hopper drier-Single screw extruder- Co-extruder for color string&multi layers-Mould-Vacuum calibration tank-Spray cooling water tank-Haul off-No dust cutter-double/single disc winding/stacker-Final product inspecting&packing

Technical parameter

pipe range(mm) 20-63 20-110 75-250 90-315 110-450 250-630 400-800
extruder model SJ65/33 SJ65/33 SJ60/38 SJ75/38 SJ75/38 SJ90/38 SJ120/38
extruder power(kw) 45 75 110 160 160 280 315
max.output(kg/h) 130 220 410 580 580 900 1150

Machine details

900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic


Our customer&exhibition

900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic

Packing
900kg/H 1150kg/H HDPE Pipe Extrusion Machine Deep Screw Automatic
