2color/3color tooling & parts

Plastic Material:PP,ABS,PC, TPE, PE, TPU, PPSU, PEEK, PEI, PBT, PA, LSR, ASA,POM,PCTG,PC/ABS

Plastic Surface finish:Polishing finish,Texture Finish,Slik print, VDI-3400,

Drawing format:UG, IGES, STEP,x_t, AutoCAD, Solidworks,Catia, PTC Creo, DWG, PDF, etc..

Certificated:ISO13485,IATF16949, ISO14001

Range of markets:medical,Industrial,automotive,electronics,aerospace,and others

Mould Material:2343, 2344, S136, 2085, 2738,M310,M333,W300,DC53,S-7, 8407, Unimax, Viking, SKD61, NAK80,H13,P20, 718,2767

Hot runner:Synventive, Incoe, HRS, moldmasters, HUSKY, EWIKON, Guenther,BHT

Injection machine size:50T-1750T

Cavities:1-64

Product Details

housing for Rolls Royce Auto lighting with red color PC material.

Product Quick detail:

1. Cavity: family mold

2. Molding Material: PC+ABS

3. Mold type: serial mold

4. Mold style: export large size mold

5. Mold base standard: HASCO

6. Runner system: hot runner

7. Delivery terms: CIF

8. Mold life: 500K

9. Mold status: Insert mold with hardness steel

10. Cavity steel: 1.2343ESR

11. This part is a visible part so we done normally polishing on the surfaces.

12. We will add an ejector blade on the ribs and ejector sleeves or ejector pins in the boss of this part.

13. There's an undercut at this position and it needs a slider. It will also have a parting line on this side.

Product specification:

Hot runner brand: Moldmaster

Gate style: hot runner with Valve gate on the part directly

Ejection: ejector pins and sleeve

Cylinder brand: AHP Merkle for ejection

Mold unit: Metric tools

Surface finish: glossy

Combining Moldflow analysis to optimize design

Combining DFM report to optimize design

Mold structure is safty and stable

Mold have sufficient air venting

Mold have sufficient cooling line

Mold produce the Part no defective, such like sink mark, bur mark, flow mark, flush etc

Scientific trial out to find optimum injection parameter

Every procedure follow ISO9001 strictly

Before tool shipped out no any sigle open opint

We will make the lifter and (inner) slider in these undercut position.

Product advantage:

1. Mold match customer injection machine 1000T
2. Mold is desgined follow customer standard
3. Mold is bulit with safest operation when production
4. Mold is in guarantee all over the word
5. 3 Parters in different area can deal it, in Mexico,Czech and Spain can provide after-serivice on the overseas.
6. Tool have been testing and pass the CPK.
7. Tool have been bulit in High Quality and short lead time with best engineering service

Product application:

1. Use for machinery
2. Use for electronic
3. Use for automotive
4. Use for information technology industry
5. Use for Space industry
6. Use for Medical industry
7. Use for Energy industry
