Recycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass Ball
Recycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass Ball
Recycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass Ball
Recycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass Ball
Recycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass Ball
Recycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass Ball
Specifications
Brand Name :
DSTHERM
Model Number :
20-32mm
Certification :
ISO9001
Place of Origin :
Zhejiang China
MOQ :
Negotiation
Price :
Negotiation
Supply Ability :
20days /20 feet container , 35days/40 HQ
Delivery Time :
20 days
Packaging Details :
Standard exported packing or as customer request
Product Name :
Double Union Ball Valve with Brass Ball
Color :
green grey blue white etc.
Size :
20x1/2"-63×2"
Standard :
ISO15874 and DIN8007/8078
Application :
Cold or hot water supply
Shape :
Equal and Reducing
OEM&ODM :
Available
Connection :
Welding
Pressure :
high pressure ,medium pressure
Payment Terms :
L/C, T/T
Description

Recycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass BallRecycled Injection PPR Pipe Fittings Double Union Ball Valve With Brass Ball

PPR Pipe Fittings Double Union Ball Valve with Brass Ball ISO9001 DIN8077/8078 Colour OEM

Catalog No. Specification
SFV301 20x20mm
SFV302 25x25mm
SFV303 32x32mm
SFV304 40x40mm
SFV305 50x50mm
SFV306 63x63mm

Material: PPR HYOSUNG R200P from Korea , Borealis A140E
Technics: Injection
Place of Origin: Shanghai, China
Connection: Welding
Shape: Equal,
Name: PPR Female threaded Coupling
Color: Green White, Grey ,etc
Surface: Smooth
Pressure Rating: 2.0MPa
Size:20x1/2–63x2
OEM Available
Material: PPR HYOSUNG R200P from Korea,58-3A cooper for brass insert
Standard: ISO 15874: 2003, DIN8077-8078
Production temperature: -40 - +95°C
Certification: ISO9001


1.High Temperature Resistance: the maximum sustained working temperature is up to 70 °C,the maximum transient temperature is up to 95°C
2.Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
3. Corrosion Resistant: resist chemical matters or electron chemical corrosion
4. Lower Installation Costs: light weight and ease of installation can reduce installation costs
5.Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume
6. Long Life: more than 50 years under normal conditions more than 50 years under normal conditions
7. Recycled and Environment-friendly

Feature
1. Sanitary & non-toxic;
2. Corrosion resistant & not scaling;
3. High temperature resistant & high pressure resistant;
4. Heat preservation & energy efficient;
5. Light weight;
6. Elegant appearance;
7. Convenient & reliable installation;
8. Long service life: over 50 years



Application Field
Potable water pipe networks for cold and warm water installations of residential
buildings, hospitals, hotels, schools, office buildings and shipbuilding
Pipe networks for rainwater utilization systems
Pipe networks for compressed air plants
Pipe networks for swimming pool facilities
Pipe networks for solar plants
Pipe networks in agriculture and horticulture
Heating pipes for residential housing
Pipe networks for industry,

For Water Installations


Temperature		 Service life Safety-factor=1.5
SDR 11 SDR 9 SDR7.4 SDR 6
Nominal Pressere
PN10 PN12.5 PN16 PN20
Permissible Working Pressure
20℃ 1 15.0 18.9 23.8 30.0
10 13.7 17.3 21.7 27.2
50 12.9 15.9 20.4 25.7
40℃ 1 10.8 13.6 17.1 21.2
10 9.2 12.4 16.0 20.2
50 9.2 11.5 14.5 18.8

50℃		 1 9.2 10.8 14.5 18.3
10 8.2 10.5 13.1 16.5
50 7.7 9.8 12.2 15.4
60℃ 1 / / 12.2 15.4
10 / / 11.0 13.8
50 / / 10.1 12.7
75℃ 1 / / 9.9 12.3
10 / / 7.5 9.3
25 / / 6.1 7.5

SDR=Standard Dimension Ratio(diameter/wall thickness)
SDR=d/s(S=Pope series index from ISO 4065)
