Laminated Plumbing PPR Aluminum Pipe Heat Resistant For Solar Plants
Laminated Plumbing PPR Aluminum Pipe Heat Resistant For Solar Plants
Laminated Plumbing PPR Aluminum Pipe Heat Resistant For Solar Plants
Laminated Plumbing PPR Aluminum Pipe Heat Resistant For Solar Plants
Specifications
Brand Name :
DSTHERM
Model Number :
20-160mm
Certification :
ISO9001
Place of Origin :
Zhejiang China
MOQ :
Negotiation
Price :
Negotiation
Supply Ability :
20days /20 feet container , 35days/40 HQ
Delivery Time :
20 days
Packaging Details :
4m/PCS polybag
Product Name :
Aluminium Plastic PPR Laminated Plumbing Pipe PPR Pipe
Pressure :
pn10 pn12.5 pn16 pn20 pn25
Standard :
din 8077-8078
Application :
Cold or hot water supply
Size :
20-160mm
Temperature :
-40---95C, heat resistant
Function :
plumbing materials adapters for water supply sytem
Length :
4m or as your request
Description

Laminated Plumbing PPR Aluminum Pipe Heat Resistant For Solar PlantsLaminated Plumbing PPR Aluminum Pipe Heat Resistant For Solar Plants

Aluminium Plastic PPR Laminated Plumbing Pipe PPR Pipe ISO9001 Color customization 20-160mm

Product: PP-R Aluminum Composite pipe
Material: 100% PPR
Size: 16-160mm
Certificate: ISO9001
Standard: ISO15874; DIN8077/8078
Working place: -40°-95°

Series SDR9/S4/PN16
Nominal Outer
Diameter		 Diameter Wall Thickness Inner Diameter Overall Wall
Thickness		 Overall Outer
Diameter
20mm 20.0 2.3 15.4 3.4 21.9
25mm 25.0 2.8 19.4 4.0 27.1
32mm 32.0 3.6 24.8 4.8 34.1
40mm 40.0 4.5 31.0 5.8 42.3
50mm 50.0 5.6 38.8 6.9 52.3
63mm 63.0 7.1 48.8 8.4 65.3
75mm 75.0 8.4 58.3 9.6 77.8
90mm 90.0 10.1 70.0 11.5 93.3
110mm 110.0 13.7 85.8 13.7 114.0





Series SDR7.4/S3.2/PN20
Nominal Outer
Diameter		 Diameter Wall Thickness Inner Diameter Overall Wall
Thickness		 Overall Outer
Diameter
20mm 20.0 2.8 14.4 3.9 21.9
25mm 25.0 3.5 18.0 4.7 27.1
32mm 32.0 4.5 23.0 5.7 34.1
40mm 40.0 5.6 28.8 6.8 42.3
50mm 50.0 6.9 36.2 8.2 52.3
63mm 63.0 8.6 45.6 10.0 65.3
75mm 75.0 10.3 54.4 11.5 77.8
90mm 90.0 12.3 65.4 13.7 93.3
110mm 110.0 15.1 79.9 16.6 114.0


Series SDR6/S2.5/PN25
Nominal Outer
Diameter		 Diameter Wall Thickness Inner Diameter Overall Wall
Thickness		 Overall Outer
Diameter
20mm 20.0 3.4 13.2 4.5 21.9
25mm 25.0 4.2 16.6 5.4 27.1
32mm 32.0 5.4 21.2 6.7 34.1
40mm 40.0 6.7 26.6 8.0 42.3
50mm 50.0 8.3 33.2 9.6 52.3
63mm 63.0 10.5 42.0 11.8 65.3
75mm 75.0 12.5 49.8 13.8 77.8
90mm 90.0 15.0 59.8 16.4 93.3
110mm 110.0 18.3 73.2 19.8 114.0


Features:

• Material: PPR--Random Polypropylene and aluminum

• Sizes: 20mm to 110mm

• Colors: light grey, white , or other colors on request

• Connection: socket fusion joint, electro fusion joint or transition joint

•Standard: CJ/T210-2005

• Factory Certification: ISO9001, ISO14001, BV

• Applications: Cold or hot water supply, heating system including flooring heating, wall heating and radiating system, Central air conditioning system, industrial liquids transportation

Properties:

1) Healthy, bacteriological neutral, conforming to drinking water standards

2) Resistant to high temperatures, good impact strength

3) Convenient and reliable installation, low construction expenses

4) Excellent heat-insulation property from minimum thermal conductivity

5) Lightweight, convenient to transport and handle, good for labor-saving

6) Smooth inner walls reduce pressure loss and increase flow speed

7) Sound insulation (reduced by 40% compared to galvanized steel pipes)

8) Light colors and excellent design ensure suitability for both exposed and hidden installation

9) Recyclable, environment-friendly, accords with GBM standards

10) Extremely long usage life for at least 50 years

Applications:

1) Potable water For cold and warm water installations

2) For rainwater utilization systems

3) For compressed air plants

4) For swimming pool facilities

5) For solar plants

6) For agriculture and horticulture

7) Heating pipes for residential housing

8) For industry.
