Specifications
Brand Name :
DSTHERM or OEM
Model Number :
20-160mm
Certification :
ISO9001
Place of Origin :
Zhejiang China
MOQ :
3000 Meters
Price :
Negotiation
Supply Ability :
20days /20 feet container , 35days/40 HQ
Delivery Time :
20 days
Packaging Details :
Export package or as customer's request
Product Name :
PPR Plumbing Tube
Hygienic property :
Good
Specification :
20*2.0/25*2.3/32*2.9/as customer's request
Standard :
Din8077/8078
Application :
Cold or hot water supply
Thickness :
PN10, PN16, PN20, PN25
OEM&ODM :
Available
Length :
4m or as your request
Description

Double Color Nano Pipe Manufacturer CE Certification ISO PPR Pipe for Water SupplierDouble Color Nano Pipe Manufacturer CE Certification ISO PPR Pipe for Water Supplier


Manufacturer CE Certification ISO PPR Pipe for Water Supplier

· Operating life for 20 C temperature and 25 atm pressure conditions is 50 years.

· They have high resistance to chemical substances.

· They are resistant to corrosion.

· They do not cause calcification or oxidation.

· They do not affect the color, smell or taste of water.

· They are composed of smooth and shiny inner surface.

· No diameter narrowing occurs at welding points.

· They show high welding performance.

· They provide heat and sound installation.

· They are hardly flammable. (Ref: DIN 19560 and DIN 4102)

· They are environment friendly.

Parameters of the PPR Pipe SDR11/S5/PN10
Nominal Outer Diameter Diameter Wall Thickness Inner Diameter
20 20 2.0 16.0
25 25 2.3 20.4
32 32 2.9 26.2
40 40 3.7 32.6
50 50 4.6 40.8
63 63 5.8 51.4
75 75 6.8 61.4
90 90 8.2 73.6
110 110 10 90.0
160 160 14.6 130.8

Parameters of the PPR Pipe SDR9/S4/PN12.5
Nominal Outer Diameter Diameter Wall Thickness Inner Diameter
20 20 2.3 15.4
25 25 2.8 19.4
32 32 3.6 24.8
40 40 4.5 31.0
50 50 5.6 38.8
63 63 7.1 48.8
75 75 8.4 58.2
90 90 10.1 69.8
110 110 12.3 85.4
160 160 17.9 124.2

Parameters of the PPR Pipe SDR7.4/S3.2/PN16
Nominal Outer Diameter Diameter Wall Thickness Inner Diameter
20 20 2.8 14.4
25 25 3.5 18.0
32 32 4.4 23.3
40 40 5.5 29.0
50 50 6.9 36.2
63 63 8.6 45.6
75 75 10.3 54.4
90 90 12.3 65.4
110 110 15.1 79.8



Applications
1) Cold and hot water supply systems for civil and industrial constructions, e.g. in
residential buildings, hospitals, hotels, school and office buildings, ship building
2) Drinking water systems and food industry pipe works
3) Central air conditioning system
4) Irrigating system for gardens and green houses
5) Public and sport facilities such as swimming pools and stadiums
6) For rainwater utilization systems

Advantages of using PPR pipe:
♦ Health and environmental protection. Polypropylene is environmentally friendly materials, can be used to make drinking water delivery.
♦ Joint with hot melt connection, become a whole, 100 percent no leakage, other materials with silk mouth connection, its permeability less, also avoid the glue bonding of toxic.
♦ High temperature resistance, good pressure resistance, small conveying resistance.
♦ The price is cheap and affordable.
♦ Long service life, according to the national standard GB/T18742 production and use can be used for 50 years.

Payment term :LC ,TT .
Delivery time : 20days /20 feet container , 35days/40 HQ
Samples lead time: 3-7 days
MOQ: 100-4000pcs
Package: pcs/polybag, 4 meters/tube or as client's request
