Chinese melt blown nonwovens extruder automatic PP filter face mask making machine

Melt blown nonwovens extruder main parameter

1.Equipment model: 200-10P or 130-16P cotton towel pumping machine

2. Basis weight: 35-80g / sqm , soft non-woven fabric 35-80 g / sqm, market ordinary cotton non-woven fabric 35-80 g / sqm, viscose non-woven fabric 40-80g /m2

3. Original cloth width: 2120mm (roller surface: 2160mm) Actual speed: 600-900 pumping / minute / row (line speed 60-80 m / minute)the inner

4. diameter of the original cloth core: Φ76mm

5. Elongation of the original cloth: 5% -25%

6. The original cloth is directly loaded on the machine, equipped with 2 cloth return racks (chain drive rear rack), and 3 feeding shafts.

7. The cloth edge is equipped with a cutting device: the cloth edge is cut before the cloth enters the folding unit.

8. The cloth strip is vacuum-adsorbed on the cloth cutting roller, and the cloth is cut quantitatively (200mm / 130mm) according to the machinery of the cloth cutting roller, with a cutting accuracy of ± 1mm.

9. Electrical configuration and control form: Siemens PLC programming controller control, Siemens inverter speed control, Siemens touch screen Operation interface, bearing brand is SKF (main power), spin Naide low voltage switch, contactor, Omron or SICK electric eye, Yadeke or SMC cylinder, with automatic counting function, the number (1-999 pumping) can be arbitrarily set.

10. Rear cloth: pneumatic cloth

11. Counting: The number of sheets of each cloth is set on the man-machine interface. The dots are separated and the misalignment is counted. The counting accuracy is 100% accurate.

12. Correction system: motor adjustment

13. Fabric break detection: with electric eye cloth break detection system (on ejection)

14. cloth introduction method: manual

15. Overall power: 37.5KW

Melt blown nonwovens extrusion line composition

Process detailed diagram
