PET Flour Cutter Milling Machine High Speed Overload Protection Abrasion Resistance
PET Flour Cutter Milling Machine High Speed Overload Protection Abrasion Resistance
Specifications
Brand Name :
yiming
Model Number :
YMSMP-500
Place of Origin :
zhangjiagang
MOQ :
≥1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
15
Delivery Time :
25 woke days
Power :
45KW
Capacity :
120-320KG/H
Rotating motor :
30pieces
Fixed blade :
15piece
Duster :
bags
Material :
SKD11
Description

Cutter Milling Machine manufacturers

Zhangjiagang billion Ming Machinery Factory is a professional manufacturer of plastic flour mill manufacturers, the main products are PVC flour mill, PE mill, PET flour mill, EVA flour mill, nylon mill and other types of plastic flour mill.

Feature

1, Compared with other pulverizers, the capacity is 20-50 percent increased with same power and the energy is saved.

2, Install the dust collection device, reduce the dust pollution effectively.

3, The labor is reduced with fan discharge.

4, The door of main machine can be opened which is convenient to maintain and replace blades.

5, Adopt double cold(water and fan),the inner temperature of body is decreased and the material pulverized is not distortional. t is beneficial to pulverize the thermo-sensitive plastic, for example PVC,PE,PET,LDPE,PS,EPS,XPS,ABS,EVA,PPC.

Usage

1, With water spray cooling system. it is suitable for processing of thermal sensitive material. With unique water spray cooling system. When the temperature of main machine is higher than setting temperature, water spray automatically until the temperature decreased normally.

Note: less of water spray into to machine will be dryed quickly which will not affect material properties. It can be installed by your requirements.

2, The raw material become power by vibration principle of ultrasonic vortex wave pressure which is from the high speed rotating of main shaft.

The material is conveyed to screening system by wind conveying. The coarse materal is back to the milling chamber automatically, then pulverized again.

3, The blade adopt high quality steel which is treated by heating.after heat treatment, with good abrasion resistance. It is suitable for continuous running.

4, This size of machine is small with compact structure, fully sealed, no dust overflow.

5, The material is transferred based on own wind pressure.

Technical Specification

Type YMSMP-600
Electricity 380V/3PHASE/50HZ
Power Main motor 45kw
Fan 4kw
Main motor Rotating motor 30pieces
Fixed blade 15pieces
Feeding automatic vibration
Colling mode water AIR-cooled
Rotating speed minute 3700rpm
Capacity H 120-320KG

Electrical

Equopment

Shaft

 contactor1 delixi CJX-2-80 220V
contactor2 delixi CJX-2-150 220V
SKF 6314
Dusting bag

Protection

equipment

High and low voltage protection

Overload protection

Suction device

Dust collecting bag protection with 9 bags
