Energy Saved Wood Crushing Machine , Wood Shredder Machine With Suction Device
Energy Saved Wood Crushing Machine , Wood Shredder Machine With Suction Device
Specifications
Brand Name :
yiming
Model Number :
YMSMP-800
Place of Origin :
zhangjiagang
MOQ :
≥1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
15
Delivery Time :
25 woke days
Power :
75KW
Capacity :
200-550KG/H
Rotating motor :
40pieces
Fixed blade :
20piece
breaing :
nsk
duster :
bags
Description

The Manufacturer Of Wood Pulverizer Machine

The wood dust and branches in the forest are good materials that can be recovered and used to make all kinds of decorative and decorative materials. For the treatment of branches and leaves, we need to use professional equipment, wood produced by 800 Ming Machinery, which is one of them.


800 input sawdust hopper, feeder into the warehouse after oscillation milling grinding, milling in the cabin after the suction centrifugal force through the screen material device and fan through pipes into the sieving device, the material after sieving, fine material reaches the customer request directly from the bag, and no coarse material from the request arrival after the pipeline back to warehouse to mill grinding. In the whole grinding process, a small amount of dust produced by the wood 800 pulverizer is directly sucked into the dust collecting cloth through the fan, and no dust can enter into the air.

Feature

1, Compared with other pulverizers, the capacity is 20-50 percent increased with same power and the energy is saved.

2, Install the dust collection device, reduce the dust pollution effectively.

3, The labor is reduced with fan discharge.

4, The door of main machine can be opened which is convenient to maintain and replace blades.

5, Adopt double cold(water and fan),the inner temperature of body is decreased and the material pulverized is not distortional. t is beneficial to pulverize the thermo-sensitive plastic, for example PVC,PE,PET,LDPE,PS,EPS,XPS,ABS,EVA,PPC.

Usage

1, With water spray cooling system. it is suitable for processing of thermal sensitive material. With unique water spray cooling system. When the temperature of main machine is higher than setting temperature, water spray automatically until the temperature decreased normally.

Note: less of water spray into to machine will be dryed quickly which will not affect material properties. It can be installed by your requirements.

2, The raw material become power by vibration principle of ultrasonic vortex wave pressure which is from the high speed rotating of main shaft.

The material is conveyed to screening system by wind conveying. The coarse materal is back to the milling chamber automatically, then pulverized again.

3, The blade adopt high quality steel which is treated by heating.after heat treatment, with good abrasion resistance. It is suitable for continuous running.

4, This size of machine is small with compact structure, fully sealed, no dust overflow.

5, The material is transferred based on own wind pressure.

Technical Specification

Type YMSMP-800
Electricity 380V/3PHASE/50HZ
Power Main motor 75kw
Fan 11kw
Main motor Rotating motor 40pieces
Fixed blade 20pieces
Feeding automatic vibration
Colling mode water AIR-cooled
Rotating speed minute 3000rpm
Capacity H 220-550KG

Electrical

Equopment

Shaft

 contactor1 delixi CJX-2-80 220V
contactor2 delixi CJX-2-220 220V
SKF 6319
Dusting bag

Protection

equipment

High and low voltage protection

Overload protection

Suction device

Dust collecting bag protection with 9 bags
