LIANDA Sieven Screen Agricultural plastic film crusher
LIANDA Sieven Screen Agricultural plastic film crusher
LIANDA Sieven Screen Agricultural plastic film crusher
LIANDA Sieven Screen Agricultural plastic film crusher
LIANDA Sieven Screen Agricultural plastic film crusher
LIANDA Sieven Screen Agricultural plastic film crusher
Specifications
Brand Name :
LIANDA
Model Number :
DSPL-1000
Certification :
CE,ISO9001,CE ISO SGS
Place of Origin :
CHINA
MOQ :
1set
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
40 working days
Packaging Details :
Factory standard package or customized package
Capacity :
100-1000kg/h plastic crusher
Voltage :
380V/50Hz/3Phase,Customized
Use :
Waste Plastic Crusher,Film Crusher
After-sales service provided :
Engineers available to service machinery overseas,Online support,Video technical support,Field installation,commissioning and training
Warranty :
1 Year
Usage :
Waste Plastic Cusher,Waste Recycling,plastic industry
Type :
Environment-friendly,crusher of plastic,plastic crusher machine,Plastic Material grinding machine,plastic recycling machine hard material scrap plastic crusher machine
Application :
Recycle Waste Plastic,Scrap Crusher,Plastic Crushing Machine,PET bottle/PP/PE/PVC film
Name :
Waste Palstic Crushing,plastic shredder and crusher,crusher of plastic
Blades material :
SKD-11,9CrSi,9CrSi/D2/SKD-11plastic crusher
Product name :
Crushing Machine,Grinder Plastic Recycling Machine,Crusher Cleaning machine and plastic crusher machine for sale,Shreddder Machine
Description

Plastic film crusher,waste plastic crusher,plastic grinding machine,plastic waste recycling machine, waste plastic crusher

LIANDA Design

In the field of soft plastic crushing, to the toughness and high winding characteristics of LDPE fil, Agricultural/Greenhouse film and PP woven/ Jumbo/Raffia bag materials, LIADNA has designed a special "V"-shaped crushing blade frame and a back knife type knife loading structure. On the basis of the original old equipment, the production capacity is increased by 2 times.

It is also ideal machine for the secondary cutting when positioned behind pre-shredders of recycling systems.

  • Machine model
Model-XPSA 600 900 1200 1500

Motor power

(KW)

 30 55 90 110
Rotary blades Qty 8
Stable blades Qty 4
Rotating diameter 450 550 550 660
Blade material 9CrSi, SKD-11, D2 or Customized
Sieven screen

LIANDA Sieven Screen Agricultural plastic film crusher

3.Machine Details

1

Blades frame

Using "V" structure design, professional design for soft plastics;

LIANDA Sieven Screen Agricultural plastic film crusher
The 1-2mm distance between the screen and the blade is the guarantee for doubling the output, and the requirements for equipment processing and manufacturing are more difficult;
2

Crusher open

Adopt Hydraulic open.

Hydraulic tipping device can efficiently, safely and quickly improve the blade sharpening work;

 LIANDA Sieven Screen Agricultural plastic film crusher
3

The design of the plastic bottle crusher is reasonable, and the body is welded with high-performance steel;

LIANDA Sieven Screen Agricultural plastic film crusher
Adopt high-strength screws to fasten, solid structure and durable.
4

External bearing seat.

Effectively avoid the casing of the crushing of material into the bearing, improve the bearing life

LIANDA Sieven Screen Agricultural plastic film crusher
Suitable for wet and dry crushing.
5

Sieve Screen

Welded strip screen makes the materials with high sediment content such as broken mulch film and agricultural film more wear-resistant;

LIANDA Sieven Screen Agricultural plastic film crusher
6

Equipped with an enlarged pulley to increase the inertia of the crusher, which can save energy and powerfully crush.

LIANDA Sieven Screen Agricultural plastic film crusher
7

Using Siemens motors and Wafangdian bearings, high-quality configuration to ensure the stability of long-term work.

LIANDA Sieven Screen Agricultural plastic film crusher
8

Electrical elements

Adopt Star-Delta Start

LIANDA Sieven Screen Agricultural plastic film crusher

Turnkey project service(LDPE LLDPE PP plastic squeezing pelletizing machine):

1. Pre-sale: we given client the details technician offer etc
2. In-sales: we supply the details layout, installation instruction, technician support for the clients
3. After sales: we arrange engineer to install the machinery and training the workers for client
4. We have 24 hours team to solve the after sales problem
5. We have free spare parts with the machine
6. We supply long term spare parts for every customer
7. We always up date the new technology to every customer
