SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
SGS PLC System PBAT Plastic Film Blowing Machine
Specifications
Brand Name :
LIANDA
Model Number :
LDHW-100
Certification :
CE,SGS,ISO9001
Place of Origin :
CHINA
MOQ :
1set
Price :
USD 10,000-USD30,000
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
40 working days
Packaging Details :
Factory standard package or customized package
Applied for :
PBAT ,PLA, PET, APET, APET, GPET, CPET, PLA, HIPS, PE, ABS, EVA ,PC, PEEK, PPS, PTFE, PEEK, TPU, TPE
Drying temperature :
can be adjustable by material property
Drying time :
20mins (can be adjustable by moisture need)
Power consumpron :
only 45% of conventional dehumidifier
Processing :
Dry and crystallization at a time
Heater :
Infrared lamps
Power source :
380V 50hz 3PHASE or Customized
Control system :
Siemens PLC
Delivery time :
30 working days
Certificate :
CE,IS09001, SGS
Applicable industy :
Plastic moulding
Description

PBAT Dryer machine, plastic dehumidifying dryer,dehumidify dryer supplier

What Can We Do For You ?

Infrared drying technology offers the ability to dry and crystallize materials in minutes, compared to hours with conventional drying equipment which reduces change over times significantly and reduces energy consumption at almost 45%, Also Infrared drying technology changes in moisture at beginning will dry pellets gently to a uniform degree within minutes, the final moisture can be about 50ppm

SGS PLC System PBAT Plastic Film Blowing Machine

  • Crystallization and drying in one process step
  • Reduction of dwell time to approximately 15-20minutes
  • About 40 % energy savings compared to conventional processes
  • Excellent mixing properties of the material during crystallization by adapted drum design, flexible temperature ramps and modular machine concept
  • Capacities from 100 kg/h to 1000kg/h economically feasible
  • Adopt Drum rotation will make sure the constant movement of the raw material to avoid clumping/sticking and dry evenly
  • Cooling the pellets to 40°C (Re-cooling the pellets to avoid the pellets re-moistured

SGS PLC System PBAT Plastic Film Blowing Machine

HOW TO WORK

SGS PLC System PBAT Plastic Film Blowing Machine

1. Material Feeding 2. Rotary Drying and Crystallization 3. Discharging

Application

Heating.Heating granules and regrind material prior to further processing (e.g. PVC, PE, PP,…) inter alia to improve the throughput in the extrusion.

Crystallization.Crystallisation of PET (Bottleflakes, granules, flakes), PET masterbatch, CO-PET, PBT, PEEK, PLA,PBAT, PPS, etc.

Drying.Drying of plastic granules, and –ground material (e.g. PET, PBT, ABS/PC, HDPE, LCP, PC, PP, PVB, WPC, TPE, TPU) as well as other free-flowing bulk materials.

Coating.Coating of adhesives (e.g. Hot melt, EVA+lime,…)

High input moisture.Drying processes with high input moisture >1%.

Diverse.Thermal processes for the removal of rest oligomeren and volatile components.

Machine Model

Model Number IRD-80 IRD-200 IRD-300 IRD-500 IRD-1000

Output/Capacity

KG/H

 80-120 200 300 500 800-1000

Installation Heating power

KW

 18 27 36 48 90
Drying time

Normally 20mins

And the drying time can be adjustable by PLC on customer’s requirement on final moisture
Control By Siemens Touch Screen PLC system
Processing Dehumidifier and crystallized at a time
Final moisture 30-70ppm
Heating way Infrared lamps
Energy saving Up to 45%
Space saving Up to 300%
Operation Faster to start up
Quick change-over and shutdown time

Our Advantage

Infrared Crystal Dryer

 Conventional Crystallizer
1

Easy to clean

The drum can be opened completely,no hidden spots and can be cleaned easily with a vacuum cleaner

 Have to be completely disassembled,cleaned and fixed
2 Rotary drying system, its rotating speed can be increased as high as possible to get an excellent mixing of pellets. It is good in agitation, the masterbatch will not be clumped Poor agitation,easy to be clumped
3 Can satisfy different type of Masterbatch (Drying temperature and time can be adjustable by the property of raw material) The drying temperature is fixed
4 Crystallization time 15-20mins depends on the material kind Need 4-6 hours or more
5

Save about 40% energy consumption compared to conventional dehumidifier

WORKING VIDEO OF INFRARED ROTARY DRYER

SGS PLC System PBAT Plastic Film Blowing Machine

Contact Us

SGS PLC System PBAT Plastic Film Blowing Machine

SGS PLC System PBAT Plastic Film Blowing Machine

HOW TO ENSURE THE QUALITY!

● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
● Each component before assembly needs strictly control by inspecting personnel.
● Each assembly is in charged by a master who has working experience for more than 20 years
●After all the equipment are completed, we will connect all the machines and run the full production line to ensure the stable running in customers' factory



Our ServiceSGS PLC System PBAT Plastic Film Blowing Machine
1. We will provide testing if the customer comes to visit factory to see the machine.
2. We will provide detail machine technical specification ,electric diagram,installation,operation manual and all the documents which customer needed for clearing customs and using the machine.
3. We will provide engineers for helping installation and training the workers at customer's site.
4. Spare parts are available when they are needed .Within warranty time,we we will provide spare parts free,and over warranty time,we will provide spare parts with factory price.
5. We will provide technical support and repair service in the whole lifetime .
