D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
Specifications
Brand Name :
LIANDA
Certification :
CE,SGS,ISO9001
Place of Origin :
CHINA
MOQ :
1set
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
40 working days
Packaging Details :
Factory standard package or customized package
Shaft design :
Single shaft
After-sales service provided :
Engineers available to service machinery overseas
Voltage :
380V 50HZ 3PHASE or Customized
Warranty :
1 year
Application :
Plastic lumps,PP/PE Film, Jumbo bag, Agricultural gound film, Baled films,
Keyword :
Single shaft shredder, waste plastic granulator, Plastic shredder, Paper shredder, Rubber tire shredder etc
Product name :
Single shaft shredder,PP PE film waste recycling plastic crusher
Description

plastic film shredder,agricultural shredder machine,hdpe shredder,plastic film recycling machine,plastic grinder

  • LIANDA Design

The single shaft crusher is a medium-to-low-speed, large-torque crushing equipment with a wide range of applications in solid waste treatment equipment. The crushed materials can be sold as raw materials or processed by other equipment to produce other products.

The single-shaft shredder machine provided by LIANDA is used for processing: suitable for crushing tough or medium-hard materials that are packaged into bundles, such as film, plastic bottles, etc., large-size or high-hardness materials (thick-walled tubes, pallets, turnover Box, etc.)

The single-shaft shredder is equipped with a swing arm pushing design and a PLC automatic control system to achieve higher output. The large-capacity hopper and the crushing bin are combined with the horizontal horizontal pushing system to maximize its ability to shred high-hardness and large-size materials

  • Applied for

Wood

Wooden pallets, round logs, wood scraps, etc.

Paper

Document paper, wrapping paper, cardboard, etc.

Aluminum

Cans, aluminum chips, etc.

Cable

Copper core, aluminum core cable and composite cable

Plastic

General purpose plastics such as injection molding, extrusion, blown film, etc., head block materials, etc.

Chemical fiber

Carpets, labor insurance clothing,stable fiber etc.

Sponge

Industrial waste, etc.

Composite material

Fiberglass products, automobile windshield, sealing tape, etc.

  • Machine model
Model 600 800 1200 1600

Motor power

(KW)

 22 55 75 132
Rotary blades Qty 26 45 64 120
Stable blades Qty 2 4 4 4
Rotating length 600 800 1200 1600
Blade material SKD-11, D2 or Customized

D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine

Machine Details

1

① Rotary blades ② Blades roller

③ Fixed blades ④ Sieve Screen

The cutting part is composed of a blade roller, rotary blades, fixed blades and sievescreen.

D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine

D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine

The minimum installation gap between the rotary blades and the fixed blades is 0.1mm

Integral processing knife roller to ensure the cutting gap between the Rotary blades and the fixed blades

The rotor knife is made of special heat-treated DC53 die steel. They can be rotated and used on four sides before replacing
The motor drives the blade roller to rotate at a high speed through the reducer, so that the rotary blades mounted on the blade roller and the fixed blade form a cut. After one cut, if the size of the material is smaller than the diameter of the sieve screen, it will be discharged from the mesh, otherwise two or more cuttings on the raw material will be carried out in the cutting room, and the material can be discharged until the discharge size is reached.

D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine

The screen can be disassembled and replaced to change the particle size of the material
2

Forced feeding by pusher to improve production efficiency

D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
Adopt high-strength screws to fasten, solid structure and durable.
3 Sealed bearing protection design, which can be waterproof and dustproof, and enlonger the service life of the bearing

D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
4

Siemens PLC monitors the motor current in real time, and the knife axis automatically reverses when the load is overloaded to protect the motor;

D2 Blade Plastic Film Shredder , Hdpe Film Recycling Machine
5 Equipped with a cutter shaft cooling system for materials with low melting points to prevent the materials from being burnt due to excessive temperature.
6 The equipment has passed CE certification and complies with EU safety standards
