Anti stress SS304 2500kg/H Dehumidifying Honeycomb Dryer
Anti stress SS304 2500kg/H Dehumidifying Honeycomb Dryer
Anti stress SS304 2500kg/H Dehumidifying Honeycomb Dryer
Anti stress SS304 2500kg/H Dehumidifying Honeycomb Dryer
Anti stress SS304 2500kg/H Dehumidifying Honeycomb Dryer
Anti stress SS304 2500kg/H Dehumidifying Honeycomb Dryer
Specifications
Brand Name :
JIN MACHINE
Model Number :
S-jin-2500
Certification :
CE Certificate
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
10 sets per month
Delivery Time :
40 work days
Packaging Details :
Standard wooden frame and wooden case is available for Jin Machine Excellent Rigid Packaging drying dryer for plastic recycling
Product :
Honeycomb Dryer
Application :
Plastic ( PE, PET, TPU, PA...)
Capacity :
2500 kg/h
Warranty :
12 Months
Heater Power :
40kw
Voltage :
220v 380v
Actual Power :
100KW
Description

Dehumidifying Honeycomb Dryer 304 Stainless Steel Material Manual Installation

1. Product Description

CSG series is a fully automatic drying system with zeolite desiccant beds, which can be used with Hopper Bank Series and multi-hopper systems. It can adapt and automatically control operating parameters based on type and quantity of polymer.Up to 40% energy saving in comparison with traditional dryers

1. Ease of maintenance with access process, regeneration and air filters

2. Self-adaptive PID temperature control from 60℃ to 300℃

3. No use of cooling water

4. No moving or rotating internal parts

5. No need of manual control, Full auto-adaptive operation

6. On-board heating unit on hopper

7. Diagnostic functions,Dewpoint, heater and temperature alarm 8.Visual and audible alarms available

9. Anti-stress function protecting polymers against overheating

10. Sturdy, well proven design for extended operational life

11. Visual and audible alarms available

12. Automatic dew point control system: not switch to new desiccant bed before the dew point gets -30°C

2. Main Technical Parameters

Model

 Volume(L) Capability(kg) Dry Fan(KW) Rebirth Fan(KW) Drying Heating(KW) Rebirth Heating(KW) Material Drying Material
CSG-315 315 200 3 0.37 15 7.5 304 Stainless Steel Molecular Seive
CSG-800 800 500 5.5 1.1 24 12 304 Stainless Steel Molecular Seive
CSG-1600 1600 1000 7.5 1.5 36 18 304 Stainless Steel Molecular Seive
CSG-3200 3200 2000 18.5 3 54 27 304 Stainless Steel Molecular Seive
CSG-5000 5000 3000 22 4 63 36 304 Stainless Steel Molecular Seive
CSG-8000 8000 5000 33 4 96 36 304 Stainless Steel Molecular Seive

3. Introduction of the series

This series expands CSG standard series maintaining its characteristics while offering increased production capacity.
Its advanced thermodynamics based on zeolite trible tower design with three desiccant cartridges and three pumps technology: two to process air production and one for saturated tower regeneration.
1. High-performance 3-bed
2. Three pumps
3. Dew point -30℃ to -70℃, dewpoint monitor
4. Dedicated to large-scale production up to 1200kg/h

Anti stress SS304 2500kg/H Dehumidifying Honeycomb Dryer
