Automobile Interior Combustion Electronic Test Instrument Horizontal Flammability Tester
Automobile Interior Combustion Electronic Test Instrument Horizontal Flammability Tester
Automobile Interior Combustion Electronic Test Instrument Horizontal Flammability Tester
Automobile Interior Combustion Electronic Test Instrument Horizontal Flammability Tester
Specifications
Brand Name :
GC
Model Number :
GC-NS-A
Certification :
ISO
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiated
Payment Terms :
TT
Supply Ability :
100 Sets
Delivery Time :
In stock
Packaging Details :
Wooden package
Flame Height :
10-100mm
Temperature Range :
Room temperature to 1000°C
Power Supply :
220V/50Hz
Chamber Size :
300mm x 300mm x 300mm
Timer :
0-99 minutes
Ignition Source :
Propane burner
Safety Features :
Over-temperature protection, gas leakage alarm
Heating Element :
Kanthal A1 wire
Chamber Material :
Stainless steel
Gas Flow Rate :
0-10L/min
Sample Size :
50mm x 50mm
Certifications :
CE, ISO 9001:2015
Temperature Control Accuracy :
±1°C
Description

Automobile Interior Combustion Test Machine

Product description:


The GC-NS-A combustion tester is suitable for the horizontal combustion characteristics of automotive interior materials, mainly refers to the automotive products used in the interior modification of the car, involving all aspects of the interior of the car, such as car sunscreen film, car handshake cover, car floor mat, Car anti-skid pads, cushions, etc.

Test Standards
GB8410-2006 Combustion characteristics of automotive interior materials
ASTM D5132-2004 Standard Test Method for the Horizontal Burning Rate of Polymeric Materials Used in the Passenger Compartment of Motor Vehicles

Technical Parameter

Model

GC-NS-A

Box size

60*22*40(cm)

Flame time

0-99 minutes and 99 seconds can be set, accuracy ±0.1 second

Residual flame time

0-99 minutes and 99 seconds can be set, accuracy ±0.1 second

Burning angle

90°

Burner size parameters

The inner diameter of the nozzle is 9.5mm, the effective length of the nozzle is 100mm, and there are air-conditioning holes

Flame height

It can be adjusted from 20mm to 100mm as required by standard

Thermometer

150℃,accuracy: 1℃

Steel ruler

length: 500mm, accuracy: 1mm

Burning gas

High purity liquefied gas
