220L Hollow Plastic Container PC Bottle Blow Molding Machine
Performance and advantages:
·Suitable for producing different kinds of safety barrel,traffic divided blocks.
·Optional bottom sealing,product eject,core-pulling movement elements.
·Adopt high output extrusion system,accumulating die head.
·Optional Hydraulic Servo control system.
Technical parameters Performance | Unit | BM160 | BM230 |
Max.product volume | L | 160 | 230 |
Dry cycle | Pc/h | 300 | 280 |
Die head structure | | Accumulating type | Accumulating type |
Main screw diameter | mm | 100 | 120 |
Max. plasticizing capacity(PE) | kg/h | 240 | 350 |
Driving motor | Kw | 90 | 132 |
Accumulating volume | L | 18 | 24 |
Oil pump motor power | Kw | 22 | 22 |
Clamping force | KN | 800 | 900 |
Space between platen | mm | 500-1400 | 800-1800 |
Platen size W*H | mm | 1120*1200 | 1320*1600 |
Max. mould size | mm | 900*1450 | 1200*1800 |
Heating power of die head | Kw | 30 | 36 |
Machine dimension L*W*H | m | 7*3.5*4 | 8.2*3.5*5.5 |
Machine weight | T | 20 | 36 |
Total power | Kw | 172 | 230 |
Note: Informations listed above are for reference only, the production line can be designed by customer’s requirements.
Application:
- Automotive industry – Many of the parts storing fluids use blow molding. Cooling system overflow containers, windshield washer fluid bottles, and even fuel tanks are commonly made with blow molding.
- Appliance components – Your major appliances at home include reservoirs that contain fluids and help to wash your clothes and dishes. These are commonly made via blow molding.
- Medical supplies and parts – If you’ve been to a health clinic, your dentist, or to visit your family doctor you can quickly start counting how many hollow containers are used. Spray bottles, water bottles, and storage containers line the cabinets. All of those are quickly made with blow molding.
- Children’s toys – If you have a small child, you could quickly count how many hollow lightweight toys they have. Blocks and squeeze toys are common uses for blow molding.
- Lawn and garden items – You could almost put lawn and garden into the automotive and bulk container categories as it uses bottles for liquid products and uses blow molding for mowers and power equipment for fuel tanks, oil storage and distribution.
- Marine – Products that go in the water need to be buoyant, and blow molding makes hollow products with ease. Reservoirs, buoys, and other items are commonly made with blow molding.
- Packaging – Customized packaging with Polystyrene keep products safe, and blow molding makes hard to create shapes with ease.
- Sporting Goods – A common blow molded product in sporting goods is a plastic bat, a plastic ball, or another hollow piece of equipment.
- Industrial bulk containers – Think of larger fluid containers like barrels to transport and store water, oil, or anything else liquid. Those are made with blow molding.
CERTIFICATES
Our Products Have Passed Many Certificates.

FAQ
1. How soon can I get a quotation?
For most projects, once we know the necessary information about the recycled raw material, we can provide you with a quotation within 24 hours.
2. Can I have a customized design?
We design and construct each project according to customer's needs.
3. How do I know I can trust ordering from you?
Jwell is the top class manufacturer of plastic machinery in China.The first screw was made by our company(JIN HAI LUO) in 1978.We provide professional extruder and all kinds of extrusion line,such as pipe,sheet, profile, plate, film,blow moulding and recycling extrusion line.We have delivered our machines to over 170 countries.We also have overseas offices in many countries.Customers are satisfied with the machines and our service.
