Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Brass Round Shape Pipes Tubes Top Brand H62 H65 H68 H70 Straight Copper Pipe
Specifications
Brand Name :
Antai
Model Number :
H62 H65 H68 H70
Place of Origin :
China
MOQ :
1 TON
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Ton Per Month
Delivery Time :
10 days
Packaging Details :
Standard export packaging
Specification: :
Wall thickness 0.2-120mm
Type: :
Straight Copper Pipe
Length: :
As required
Alloy Or Not: :
Alloy
Elongation (≥ %): :
30
Outside Diameter: :
Outside Diamter 2~914mm
Temper: :
1/4H 1/2H Hard Soft
Payment terms: :
L/C T/T (30%DEPOSIT)
Ultimate Strength (≥ MPa): :
440
Wall Thickness: :
Wall thickness 0.2-120mm
Processing Service: :
Bending, Decoiling, Welding, Punching, Cutting
Standard: :
ASTM B42/68/88/280/111/640/447
Surface: :
mill finish polished
Description
Name Copper/brass/bronzePipe/tube
Size diameter:6_630mm/customized thicknesd:0.6-30mm/customized
Surface Polishedbrightoiledhair linebrushmirroror as required
MOQ Negotiable
Quality Control Mill Test Certification is supplied with shipmentThird Part Inspection is acceptable
required Export to Ireland.Sinaapore.Indonesia.UkraineSaudi ArabiaSpainCanada.USA
Brazil,ThailandKoreaItalyIndiaEgyptOmanMalaysiaKuwaitCanadaViet Nam Peru Package Plastic flm with Wooden case orwooden
pallet Delivery time Prompt delivery or upon your order quantity

Product Name brass tube/pipe

Material

GB standard
H96,H90,H85,H80,H70,H68,H65,H63,H62,H59,etc
ASTM standard
C21000,C22000,C22600,C23000,C24000,C26000,C26130,

C26800,C27000,
C27200,C27400,C28000,C31400,C31600,C32000,C33200,

C33300,C33500,
C34000,C34200,C34500,C35000,C35300,C35600,C36000,

C36500,C37000,
C37700,C38000,C38500,C40500,C40800,C40810,C40850,

C40860,C41100,
C41300,C41500,C42200,C42500,C42520,C42600,C43000,

C43400,C44300,
C44400,C44500,C46200,C46400,C46500,C47940,C48200,

C48500,C50500,
C50580,C50700,C51000,C51080,C51100,C51180,C51900,

C51980,C52100,
C52180,C52400,C52480,C53400,C54400,C60600,C60800,

C61300,C61400,
C61900,C62300,C62400,C63000,C63020,C63200,C64200,

C64210,C64700,
C65100,C65400,C65500,C66100,C66400,C66410,C66430,

C66700,C67000,
C67500,C67600,C68700,C68800,C69100,C69400,C69430,

C69700,C69710,
C70250,C70260,C70265,C70400,C70600,C70620,C71000,

C71500,C71520,
C71640,C72200,C72400,C72500,C72650,C72700,C72900,

C73500,C74000,
C74500,C75200,C75700,C76200,C76400,C77000,C77400,

C79200,etc
JIS standard
C2051,C2100,C2200,C2300,C2400,C2600,C2680,C2700,

C2720,C2800,
C2801,C3501,C3560,C3561,C3601,C3602,C3603,C3604,

C3605,C3710,
C3712,C3713,C3771,C4250,C4430,C4621,C4622,C4640,

C4641,C5101,
C5102,C5111,C5191,C5210,C5212,C5341,C5441,C6140,

C6161,C6191,
C6241,C6280,C6301,C6561,C6711,C6712,C6782,C6783,

C6870,C6871,
C7060,C7150,C7100,C7164,C7351,C7451,C7521,C7541,

C7701,C7941,
etc
Surface Treatment Mill polished,Bright,Oiled,Hair line,Brush,Mirror,Sand blast,etc


Size		 O.D: 2-480mm or customized
Length: 1-12m
Standard ASTM, DIN, GB, JIS, BS, AISI
Packing Export standard package or as customers' request
Delivery time Usually 7-15 dyas, or upon negotiation
Price terms FOB,CRF,CIF,EXW all acceptable

Alloy Chemical Composition(%)
QB JIS/UNS Cu Pb Zn Fe Total Impurity
H62 C2800 60.5~63.5 ≤0.08 REM ≤0.15 ≤0.5
H65 C2680 63.5~68.0 ≤0.03 REM ≤0.1 ≤0.3
H70 C2600 68.5~71.5 ≤0.03 REM ≤0.5 ≤0.1
H80 C2400 79~81 ≤0.03 REM ≤0.5 ≤0.1
H90 C2200 88.0~91.0 ≤0.03 REM ≤0.1 ≤0.1
H96 C2100 95.0~97.0 ≤0.03 REM ≤0.1 ≤0.2

Brass Alloy Tensile Strength (N/mm) Elongation(%) Hardness (HV)
Soft 1/2H H Soft 1/2H H Soft 1/4H 1/2H 3/4H H
C2100 (H96) ≥205 270-345 ≥280 ≥33 ≥18 — ≤65 65~80 80-100 — ≥100
C2200 (H90) ≥225 295-365 ≥320 ≥35 ≥20 — ≤70 70~95 95-120 — ≥120
C2300 (H85) ≥245 310-385 ≥340 ≥40 ≥23 — ≤70 70~95 95-120 — ≥120
C2400 (H80) ≥255 320-405 ≥375 ≥44 ≥25 — ≤80 75-105 100-130 — ≥125
C2600 (H70) ≥295 370-440 430-510 ≥5 ≥30 ≥14 ≤90 90-105 105-130 130-145 145-160
C2680 (H65) ≥295 370-440 430-510 ≥45 ≥30 ≥14 ≤90 90-105 105-130 130-145 145-160
C2720 (H63) ≥295 370-440 430-510 ≥45 ≥30 ≥14 ≤90 90-105 105-130 130-145 145-160
C2800 (H62) ≥320 410-490 ≥450 ≥35 ≥15 — — 85-105 105-130 — ≥130
