Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words
Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words
Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words
Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words
Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words
Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words
Specifications
Brand Name :
Omron
Model Number :
CJ2M-CPU34
Packaging Details :
Carton packaging
Supply Ability :
10pc/per week
Price :
$450-$1500
Place of Origin :
China/Japan
MOQ :
1/pc
Payment Terms :
T/T, western union
Service :
One-stop service
Package :
Original Package
Quality :
new and original
Lead time :
In stock
Warrenty :
One year
Delivery Detail :
3-5 working days after payment
Max. digital :
2,560
Logic execution speed :
40 ns
Width :
62 mm
Built-in functions :
USB + EtherNet/IP, serial comm. option slot
Port :
Guangdong Shenzhen Dongguan
Description

Program capacity 30K Omron CPU CJ2M-CPU34 New in box Price

Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words

Product Features
CJ2M for basic machine automation

The CJ2M Series is ideal for packaging and general machine automation needs. Connectivity is assured thanks to the built-in USB port and the choice of Ethernet and RS-232C/422/485 interfaces on the CPU.

  • Always accessible through standard USB port
  • Standard Ethernet port with EtherNet/IP Data Link function
  • Wide range of program capacities from 5K steps to 60K steps
  • Serial option board
  • Dedicated function block memory ensures efficient execution of function block software modules
Related Products

Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words

Specification

Max. digital
I/O points

Program capacity

Data memory capacity

Logic execution speed

Max. I/O units

Width

5 V current
consumption

Built-in functions

Order code

2,560

400 K

832 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU68-EIP

2,560

250 K

512 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU67-EIP

2,560

150 K

352 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU66-EIP

2,560

100 K

160 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU65-EIP

2,560

50 K

160 K

16 ns

40

80 mm

820 mA

USB + EtherNet/IP + RS-232C

CJ2H-CPU64-EIP

2,560

60 K

160 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU35

2,560

30 K

160 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU34

2,560

20 K

64 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU33

2,560

10 K

64 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU32

2,560

5 K

64 K

40 ns

40

62 mm

700 mA

USB + EtherNet/IP, serial comm. option slot

CJ2M-CPU31

Images

Built In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K WordsBuilt In EtherNet/IP Omron CJ2 PLC CPU Unit CJ2M-CPU34 30K Steps 120K Bytes 160K Words

Accessories

Description

Remarks

Order code

High-speed data collection and storage unit, with CF card slot and Ethernet port

CPU bus unit

CJ1W-SPU01-V2

Pulse I/O option module for CJ2M CPU Units, 2 encoder inputs, 2 pulse outputs

NPN (sinking) outputs

CJ2M-MD211

Pulse I/O option module for CJ2M CPU Units, 2 encoder inputs, 2 pulse outputs

PNP (sourcing) outputs

CJ2M-MD212

CompactFlash memory card, 128 MB, for all models (not required for operation)

Industrial grade

HMC-EF183

CompactFlash memory card, 256 MB, for all models (not required for operation)

Industrial grade

HMC-EF283

CompactFlash memory card, 512 MB, for all models (not required for operation)

Industrial grade

HMC-EF583

CompactFlash PC-Card adapter

-

HMC-AP001

I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_

Push-in

XW2R-P40G-T

I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_

Clamp

XW2R-E40G-T

I/O terminal block (40-pt.) for CJ1M-CPU2_/CJ2M-MD21_

M3 Screws

XW2R-J40G-T

Connection cable between I/O terminal block and CJ1M-CPU2_/CJ2M-MD21_ ( ____ = length in cm)

MIL (40 pt)

XW2Z-____FF-L

Servo unit terminal block for 1 axis

-

XW2B-20J6-8A

Servo unit terminal block for 2 axes

-

XW2B-40J6-9A

SMARTSTEP cable for CJ1M-CPU2_/CJ2M-MD21_, cable length: 1 m

-

XW2Z-100J-A26

W-series servo cable for CJ1M-CPU2_/CJ2M-MD21_, cable length: 1 m

-

XW2Z-100J-A27

CX-One, integrated software for programming and configuration of all Omron control system components

-

CX-ONE-AL__C-E

Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port (length: 2.0 m)

-

CS1W-CN226

Connection cable, D-Sub 9-pin PC serial port to PLC peripheral port (length: 6.0 m)

-

CS1W-CN626

USB to serial conversion cable

-

CS1W-CIF31

RS-232C Option Board

1
1. Only used with CJ2M-CPU3_

-

CP1W-CIF01

RS-422A/485 Option board

1
1. Only used with CJ2M-CPU3_

-

CP1W-CIF11

RS422A/485 (isolated) Option board

1
1. Only used with CJ2M-CPU3_

-

CP1W-CIF12

Battery Set

2
2. Included with the CPU unit

-

CJ1W-BAT01

USB Programming cable

-

CP1W-CN221
