Specifications
Place of Origin :
China/Japan
Brand Name :
FUJI
Model Number :
TS2060I
Packaging Details :
Carton packaging
Supply Ability :
10pc/per week
Price :
$150-$2000
MOQ :
1/pc
Payment Terms :
T/T, western union
Condition :
100% original and new
Warranty :
1Year
Package :
Original Packing
Shipping Ways :
DHL,FedEx,EMS,Fedex
MOQ :
1 piece
Model number :
TS2060I
Brand :
Fuji Hakkp
Product name :
Touch Screen HMI
Delivery time :
7-10 working days
Port :
selectable
Description

FUJI TS2060I Color HMI Touch Screen one Year Warranty

Specification

TS2060 TS2060i
Power supply Rated voltage 24VDC
Permissible range of voltage 24VDC ± 10%
Permissible momentary power failure Within 1ms
Demand (maximum rating) 13W or less
Insulation resistance Between DC external terminal and FG: 500VDC 10MΩ or more
Physical environment Ambient temperature 0 degC ~ +50 degC *1
Ambient humidity 85%RH or less (without dew condensation) *1
Operation altitude 2,000 meters or lower
Atmosphere Not to be exposed to corrosive gas, or conductive dust
Storage temperature -10 ~ 60 degC *1
Storage humidity 85%RH or less (without dew condensation) *1
Overvoltage category Category II
Contamination level Level 2
Mechanical operating conditions Resistance to oscillation Complies with JIS B 3502 (IEC61131-2) Vibration frequency: 5-9Hz, pulsating with:3.5mm, 9-150Hz, Acceleration: 9.8m/s2(1G),X,Y,Z: 3 directions (10 times each)
Resistance to shock Complies with JIS B 3502 (IEC61131-2) Peak acceleration: 147m/s2(15G), X,Y,Z: 3 directions, three times each (18 times in total)
Electric operating conditions Resistance to noise Noise voltage: 1,000Vp-p, pulse width: 1μs, pulse rise time: 1ns
Resistance to static discharge Complies with IEC61000-4-2, contact: 6kV, air: 8kV
Installation conditions Grounding Grounding resistance: Less than 100Ω, FG/SG separation
Protection Structure Front panel: Complies with IP65 (when waterproof gasket is installed) Rear cover: Complies with IP20
Installation method Panel mounting
Cooling system Natural air cooling
Dimensions W*H*D(mm) 182.5 x 138.8 x 45.8mm
Panel cutout (mm) 174.0(-0,+0.5) x 131.0(-0,+0.5) mm (same as V806/V606e)
Case color Black
Battery Coin type lithium battery, lifetime: 5 years (ambient temperature 25 degC)
Material PC

Item# TS2060I - TS Series, 5.7" QVGA TFT, 64K C, USBA&B(Mini), 24VDC, Built-in Ethernet

Technoshot Series Information


The UL certified MONITOUCH Technoshot Series is available in a 7” and 10” screen size, and features an eco‑friendly LED backlight with a sleek, slim structure. All models come standard with two USB interfaces, allowing better connectivity to peripheral devices. Customers will enjoy the convenience of Technoshot’s simple installation, as well as its remote monitoring and maintenance capabilities due to the on‑board Ethernet port.
