FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
FREQROL-D700 Mitsubishi Electric Inverter Frequency 0.1kw FR-D720-0.1K
Specifications
Place of Origin :
China/Japan
Brand Name :
Mitsubishi
Model Number :
FR-D720-0.1K
Certification :
CE
Packaging Details :
Carton packaging
Supply Ability :
10pc/per week
Price :
$300.00 - $1,000.00/Pieces
MOQ :
1/pc
Condition :
100% Original
Warranty :
1 Year
Shipping term :
TNT DHL FEDEX Armex
Payment term :
T.T WESTUNION
Delivery time :
3-5 Working Days
Quality :
100%Brand
Package :
Orginal package
Control Method :
V/F CONTROL
Rated Motor Capacity :
0.1kw
Port :
Selectable
Payment Terms :
T/T, western union
Description

Mitsubishi frequency inverter FR-D720-0.1K FREQROL-D700 Series

FA-Inverter: Inverter

Power Loss SLD (W) N/A
Power Loss ND (W) 14
Power Loss HD (W) N/A
Power Loss LD (W) N/A
Control Method (2) N/A
Built-In Network (2) N/A
Series FR-D700 SERIES
Safe Torque Off (STO) YES
Rated Output Current ND (A) 0,8
Phases 3
Integrated Digital Inputs 5
Display Type 4 DIGITS LED
Integrated EMC Filter NO
Integrated DC Choke NO
RS-485 1
Integrated Analogue Outputs 1
Type FR-D700 COMPACT INVERTER
Rated Output Current SLD (A) N/A
Program Memory N/A
PLC Function NO
Rated Motor Capacity ND (kW) 0,1
Control Method V/F CONTROL
Integrated Analogue Inputs 2
Rated Output Current LD (A) N/A
Program Memory Unit N/A
USB NO
Brake Chopper ED (%) 30
Current Type AC
Protection Class IP20
Motor Type INDUCTION MOTOR
Display BUILT-IN
Rated Motor Capacity SLD (kW) N/A
Max. Permissible Voltage (V) 264
Digital Outputs (Transistor) 1
Rated Output Current HD (A) N/A
Expandable NO
Minimum Rated Voltage (V) 200
Min. Permissible Voltage (V) 170
Digital Outputs (Relay) 1
Rated Motor Capacity LD (kW) N/A
Type of Terminal Block SPRING CLAMP
Maximum Rated Voltage (V) 240
Built-In Network MODBUS-RTU
Rated Motor Capacity HD (kW) N/A
Regenerative (4Q) NO
Leakage Current (mA) 1
Power Loss (W) N/A
Standby Power Consumption (W) 5,5-10,5
Ethernet Port NO

Product Dimensions & Weight

Depth (mm) 80,5
Weight (kg) 0,5
Width (mm) 68
Height (mm) 128

PACKAGING DIMENSIONS & WEIGHT

Gross Weight

0.8 KG

Volume

4.05 CDM

Length

22,5 CM

Width

18 CM

Height

10 CM
