24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays
24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays
24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays
24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays
24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays
24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays
Specifications
Place of Origin :
China/Japan
Brand Name :
Omron
Model Number :
G2RV-SR700
Packaging Details :
Carton packaging
Supply Ability :
10pc/per week
Price :
$3.00 - $29.00/Pieces
MOQ :
1/pc
Warrenty: :
one year
Delivery Time: :
3-5 working days after payment
Package: :
Original
Port :
Guangdong Shenzhen Dongguan
Payment Terms :
T/T, western union
Description

Omron G2RV-SR500 24VDC Relay Socket 6A 250VAC for G2RA Series Relays

24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays24V DC Omron Relay Socket 6A 250V AC G2RV-SR700 For G2RA Relays

Features

• Realized about 25% lower profile than conventional products, contributing to further miniaturization of the control panel.

• Realized opening and closing ability with one pole 6 A slim shape.

• Micro load products for one pole 50 mA using Au-plated contacts for small load switching also available.

• Since G2RV is a transparent case, confirming the state of the contact with the naked eye is possible, and easy to confirm abnormality on-site (installed location).

• Screw terminal is also stocked to meet the screw type needs.

• Mounted relay uses plug-in terminals that are difficult to bend when exchanging.

• G3RV-SR featuring a solid state relay similar in shape to G2RV-SR also available.

Specification

ted input
voltage		 Rated current Must
operate
voltage		 Must
release
voltage		 Power consumption Maximum
allowable
voltage
AC DC Percentage of
the rated voltage		 AC (VA) DC (mW) Percentage
of the rated
voltage
50 Hz 60 Hz
12 VDC - - 27.9 mA 80% max.* 10% min. - Approx. 300 mW 110%
24 VDC - - 13.5 mA - Approx. 300 mW
24 VAC/VDC 12.5 mA 12.6 mA 12.6 mA Approx. 0.5 VA Approx. 300 mW
48 VAC/VDC 5.9 mA 6.1 mA 5.2 mA Approx. 0.4 VA Approx. 250 mW
100 VAC 5.9 mA 6.0 mA - Approx. 0.8 VA -
110 VAC 5.9 mA 5.9 mA - Approx. 0.8 VA -
200 VAC 6.6 mA 7.6 mA - Approx. 1.7 VA -
230 VAC 7.3 mA 8.4 mA - Approx. 1.7 VA -

*1. P level: λ60=0.1×10-6/times
This value is the value in switching frequency 120 operations/min.
*2. If the Au plating layer is destroyed, the number will be the same as the standard type.

Characteristics

Item Standard
(G2RV-SR700, 500, 701, 501)		 For microloads
(G2RV-SR700-AP, 500-AP)
Contact resistance * 100 mΩ max.
Operate (Set) time * 20 ms max.
Release time * AC, AC/DC: 40 ms max.
DC: 20 ms max.
Maximum operating
frequency		 Mechanical: 18,000 operations/h
Electrical: 1,800 operations/h (rated load)
Insulation resistance 1,000 MΩ min. (at 500 VDC)
Dielectric strength Between coil and contacts: 4,000VAC 50/60 Hz 1 min
Contact between the same polarity: 1,000 VAC 50/60 Hz 1 min
Vibration resistance Destruction: 10 to 55 to 10 Hz, single amplitude 0.50 mm (double amplitude 1.0 mm)
Malfunction: 10 to 55 to 10 Hz, single amplitude 0.50 mm (double amplitude 1.0 mm)
Shock resistance Destruction: 1,000 m/s2
Malfunction: Energized 200m/s2, Non-energized 100m/s2
Endurance * Mechanical 5,000,000 operations min.
Electrical NO contact: 70,000 operations min.
NC contact: 50,000 operations min.		 5,000,000 operations min.
Ambient operating
temperature		 Operating: -40 to +55°C (with no icing or condensation)
Ambient operating
humidity		 Operating: 5 to 85% RH
Weight Approx. 30 g
Contact material Ag alloy Ag alloy + Au plating

Note: Above values are initial values.
* Value is at ambient temperature of 23°C.

Approved standards

UL508 (file No.E41643)

Model Contact form Operation coil ratings Contact ratings Operations
G2RV-SR series SPDT 12 to 48 VDC
24 to 230 VAC		 6 A at 250 VAC (Resistive load)
6 A at 30 VDC (Resistive load)
2 A at 400 VAC (Resistive load)*		 6,000

* If the load voltage exceeds 250 VAC, please attach with a spacing of 12 mm min., or use a separate plate (XW5Z-EP12).

TÜV (EN 61810-1)

Model Contact form Operation coil ratings Contact ratings Operations
G2RV-SR series SPDT 12, 24 VDC
24, 48 VAC/VDC
100, 110, 200, 230 VAC		 6 A at 250 VAC (Resistive load)
6 A at 30 VDC (Resistive load)
2 A at 400 VAC (Resistive load)*		 50,000
50,000
6,000

* If the load voltage exceeds 250 VAC, please attach with a spacing of 12 mm min., or use a separate plate (XW5Z-EP12).

Lloyd's (File No.07/10020)

Model Contact form Operation coil ratings Contact ratings
G2RV-SR500
G2RV-SR700		 SPDT 12, 24 VDC
24, 48 VAC/VDC
100, 110, 200, 230 VAC		 6 A at 250 VAC (Resistive load)
2.5 A at 250 VAC (PF0.4)
6 A at 30 VAC (Ress)
2 A at 30 VDC (L/R=7ms)
G2RV-SR501
G2RV-SR701		 SPDT 12, 24 VDC
24 VAC/VDC		 6 A at 250 VAC (Resistive load)
2.5 A at 250 VAC (PF0.4)
6 A at 30 VAC (Ress)
2 A at 30 VDC (L/R=7ms)
G2RV-SR500-AP
G2RV-SR700-AP		 SPDT 12, 24 VDC
24, 48 VAC/VDC
100, 110, 200, 230 VAC		 0.05 A at 30 VAC (Resistive load)
0.05 A at 36 VDC (Resistive load)
