Specifications
Brand Name :
Euchner
Model Number :
SN02R12-502-M
Certification :
UL,CCC,etc.
Place of Origin :
Germany
MOQ :
1
Price :
variable
Payment Terms :
T/T
Supply Ability :
100PCS/MONTHS
Delivery Time :
Negotiate
Packaging Details :
Carton
Manufacturer :
Euchner
Product NO. :
SN02R12-502-M
Product type :
Limit Switch
Warranty :
1 Year
Moq :
1 Set
Description

Euchner SN02R12-502-M (ORDER NO. 079287) Limit Switch PN 079287 Travel Switch Series SN... 12 mm, mechanical

Specification

Part Number: SN02R12-502-M
Manufacturer: Euchner
Condition : Brand New
Warranty : 12 months
Product Type Limit Switch

Euchner SN02R12-502-M ORDER NO. 079287 Limit Switch PN 079287 Travel Switch Series SN... 12 Mm, Mechanical

Euchner SN02R12-502-M ORDER NO. 079287 Limit Switch PN 079287 Travel Switch Series SN... 12 Mm, Mechanical

Euchner SN02R12-502-M ORDER NO. 079287 Limit Switch PN 079287 Travel Switch Series SN... 12 Mm, Mechanical

Electrical connection values

Connection cross section 0.34 ... 1.5 mm²
Rated insulation voltage Ui 250 V
Rated impulse withstand voltage Uimp 2.5 kV
Utilization category
AC-15 6 A 230 V
DC-13 6 A 24 V
AC-12 8 A 250 V
Short circuit protection according to IEC 60269-1 8A gG
Switching current
min. at DC 12V min. 10 mA
thermal rated current Ith 8 A

Mechanical values and environment

Approach speed 0.01 ... 80 m/min
Connection type
2 x M20 x 1.5
Number NC contacts 2
Number of switching elements 2
Number of NO contacts 2
Design upright
Actuating element
Slide bearing Roller plunger
Actuating force min. 20 N
Installation orientation any
Mechanical life 30 x 10⁶
Switching principle Snap-action switching contact
Degree of protection IP67
Plunger spacing 12 mm
Ambient temperature -5 ... +80 °C
Material
Contact Silver alloy, gold flashed
Housing Die-cast aluminum, anodized
