Brand

B&R

Model Number

8V1022.00 - 2

Product Type

Servo Drive (ACOPOS)

Application Areas

Wood industry, textile industry, metalworking industry, and general industrial automation

Mains Input Voltage

3x 400 - 480 VAC ± 10%
3x 230 VAC ± 10%

Frequency

50 / 60 Hz ± 4%

Installed Load Max.

3 kVA

Inrush Current at 400 VAC

4 A

Switch - on Interval

> 10 s

Integrated Line Filter

Yes (per EN 61800 - 3, category C3)

Power Dissipation at Device Nominal Power without Braking Resistor

Approx. 120 W

DC Bus Capacitance

235 μF

24 VDC Power Supply Input Voltage

24 VDC ± 25%

24 VDC Power Supply Input Capacitance

8200 μF

24 VDC Power Supply Current Consumption

Max. 2.5 A + current for motor holding brake

Motor Connection Quantity

1

Continuous Current

2.2 A eff

Peak Current

14 A eff

Nominal Switching Frequency

20 kHz

Possible Switching Frequencies

5 / 10 / 20 kHz

Max. Motor Line Length

25 m

Protective Measures

Overload protection, short - circuit and ground fault protection

Max. Output Frequency

598 Hz

Terminal Connection Cross Section (Flexible and Fine - Stranded Wires with Wire End Sleeve)

0.25 to 4 mm²

Approbation Data (UL / c - UL - us)

30 to 10 awg

Approbation Data (CSA)

28 to 10 awg

Motor Holding Brake Connection Response Threshold for Open - Circuit Monitoring

Approx. 385 mA

Motor Holding Brake Connection Max. Output Current

1 A

Motor Holding Brake Connection Max. Number of Switching Cycles

Unlimited (implemented electronically)

Braking Resistor Peak Power Output

3.5 kW

Braking Resistor Continuous Power

130 W

Limit Switch and Reference Inputs Quantity

3

Limit Switch and Reference Inputs Circuit

Sink

Limit Switch and Reference Inputs Electrical Isolation (Input - ACOPOS)

Yes

Limit Switch and Reference Inputs Electrical Isolation (Input - Input)

No

Limit Switch and Reference Inputs Nominal Voltage

24 VDC

Limit Switch and Reference Inputs Maximum Voltage

30 VDC

Limit Switch and Reference Inputs Switching Threshold (Low)

< 5 V

Limit Switch and Reference Inputs Switching Threshold (High)

> 15 V

Limit Switch and Reference Inputs Current at Nominal Voltage

Approx. 4 mA

Limit Switch and Reference Inputs Switching Delay Max.

2.0 ms

Limit Switch and Reference Inputs Modulation Compared to Ground Potential Max.

± 38 V

Enable Inputs Quantity

1

Enable Inputs Circuit

Sink

Enable Inputs Electrical Isolation (Input - ACOPOS)

Yes

Enable Inputs Nominal Voltage

24 VDC

Enable Inputs Maximum Voltage

30 VDC

Enable Inputs Input Current at Nominal Voltage

Approx. 30 mA

Enable Inputs Switching Threshold (Low)

< 5 V

Enable Inputs Switching Threshold (High)

> 15 V

Enable Inputs Switching Delay (Enable 0 → 1, ready for PWM)

Max. 100 μs

Enable Inputs Switching Delay (Enable 1 → 0, PWM off)

Max. 2.0 ms

Enable Inputs Modulation Compared to Ground Potential Max.

± 38 V

OSSD Signal Connections

Not Permitted

Trigger Inputs Quantity

2

Trigger Inputs Circuit

Sink

Trigger Inputs Electrical Isolation (Input - ACOPOS)

Yes

Trigger Inputs Electrical Isolation (Input - Input)

No

Trigger Inputs Nominal Voltage

24 VDC

Trigger Inputs Maximum Voltage

30 VDC

Trigger Inputs Switching Threshold (Low)

< 5 V

Trigger Inputs Switching Threshold (High)

> 15 V

Trigger Inputs Current at Nominal Voltage

Approx. 10 mA

Trigger Inputs Switching Delay (Rising Edge)

52 μs ± 0.5 μs (digitally filtered)

Trigger Inputs Switching Delay (Falling Edge)

53 μs ± 0.5 μs (digitally filtered)

Trigger Inputs Modulation Compared to Ground Potential Max.

± 38 V

Electrical Discharge Capacitance

660 nF

Energy Efficiency (ie Classification)

ie2 (10, 25): 3.8%
ie2 (50, 25): 3.8%
ie2 (10, 50): 4%
ie2 (50, 50): 4%
ie2 (90, 50): 4.1%
ie2 (10, 100): 4.3%
ie2 (50, 100): 4.4%
ie2 (90, 100): 4.7%
Nominal losses in standby mode: 13.2 W

Permissible Mounting Orientations

Hanging vertically: Yes
Horizontal, face up: Yes
Standing horizontally: No

Installation Elevation above Sea Level (Nominal)

0 to 500 m

Installation Elevation above Sea Level (Maximum)

2000 m

Pollution Degree per EN 61800 - 5 - 1

2 (non - conductive pollution)

Overvoltage Category per EN 61800 - 5 - 1

II

Degree of Protection per EN 60529

IP20

Ambient Temperature (Operation - Nominal)

5 to 40 °C

Ambient Temperature (Operation - Maximum)

55 °C

Ambient Temperature (Storage)

- 25 to 55 °C

Ambient Temperature (Transport)

- 25 to 70 °C

Relative Humidity (Operation)

5 to 85%

Relative Humidity (Storage)

5 to 95%

Relative Humidity (Transport)

Max. 95% at 40 °C

Dimensions (Width)

70.5 mm

Dimensions (Height)

375 mm

Dimensions (Depth)

235.5 mm

Weight

4.0 kg

Certifications

CE, UKCA, Functional safety, UL cULus e225616, Power conversion equipment (KC)

Slots for Plug - in Modules

4

Included in Delivery

Shielding component sets (8 x 0010.00 - 1 ACOPOS shielding components set for 8V1022.xxx - x up to 8V1090.xxx - x), Terminal sets (8 x 0001.00 - 1 ACOPOS accessories, connector set for 8V1010.00 to 8V1090.00 (3 - phase))

Optional Accessories

Plug - in modules such as 8AC110.60 - 3 ACOPOS plug - in module (CAN interface), 8AC114.60 - 2 ACOPOS plug - in module (Powerlink v2 interface), etc.
