deTec C4C-SA18030A10000, Product data sheet - SICK Retroreflective Photoelectric Sensor
deTec C4C-SA18030A10000, Product data sheet - SICK Retroreflective Photoelectric Sensor
Specifications
Brand Name :
SICK
Model Number :
C4C-SA18030A10000
Certification :
3C
Place of Origin :
GERMANY
MOQ :
1
Price :
336$/piece
Payment Terms :
T/T
Supply Ability :
1piece in stock
Delivery Time :
3 day
Packaging Details :
200*50*50mm
Resolution :
30 mm
Wave length :
850 nm
No blind zones :
Yes
Description
Features
Sub product family deTec4 Core
Application Normal industrial environment
System part Sender
Compatible receiver 1211510
Resolution 30 mm
Scanning range 15 m
Protective field height 1,800 mm
No blind zones Yes
Synchronization Optical synchronization
Items supplied Sender
Safety-related parameters
Type Type 4 (IEC 61496-1)
Safety integrity level SIL 3 (IEC 61508)
Category Category 4 (ISO 13849-1)
Performance level PL e (ISO 13849-1)
PFHD (mean probability of a dangerous fail-
ure per hour)		 3.7 x 10-9
TM (mission time) 20 years (ISO 13849-1)
Safe state in the event of a fault At least one OSSD is in the OFF state.
Functions
Protective operation ✔
Automatic calibration of the protective field
width		 ✔
2 SAFETY LIGHT CURTAINS | SICK Product data sheet | 2025-01-27 16:05:04
Subject to change without notice
C4C-SA18030A10000 | deTec
SAFETY LIGHT CURTAINS
Interfaces
System connection
Length of cable
Cable diameter		 Male connector M12, 5-pin
150 mm

4.3 mm
Cable bend radius
Stationary position
Flexible use
> 12 x cable diameter
> 15 x cable diameter
Display elements LEDs
Electronics
Protection class III (IEC 61140)
Supply voltage VS 24 V DC (19.2 V ... 28.8 V)
Ripple ≤ 10 %
Power consumption typical 1.3 W (DC)
Mechanics
Dimensions See dimensional drawing
Housing material Aluminum extruded profile
Ambient data
Enclosure rating IP65 (IEC 60529)
IP67 (IEC 60529)
Ambient operating temperature –30 °C ... +55 °C
Storage temperature –30 °C ... +70 °C
Air humidity 15 % ... 95 %, Non-condensing
Vibration resistance 5 … 150 Hz, 3,5 mm / 1 g (EN 60068-2-6)
Shock resistance 15 g/ 6 ms (EN 60068-2-27)
Class 3M4 (IEC TR 60721-4-3)
Other information
Wave length 850 nm
Type of light Near-infrared (NIR), invisible
Classifications
ECLASS 5.0 27272704
ECLASS 5.1.4 27272704
ECLASS 6.0 27272704
ECLASS 6.2 27272704
ECLASS 7.0 27272704
ECLASS 8.0 27272704
ECLASS 8.1 27272704
ECLASS 9.0 27272704
ECLASS 10.0 27272704
ECLASS 11.0 27272704
ECLASS 12.0 27272704
ETIM 5.0 EC002549
2025-01-27 16:05:04 | Product data sheet SAFETY LIGHT CURTAINS | SICK 3
Subject to change without notice
C4C-SA18030A10000 | deTec
SAFETY LIGHT CURTAINS
ETIM 6.0 EC002549
ETIM 7.0 EC002549
ETIM 8.0 EC002549
UNSPSC 16.0901 46171620
