Single Mode 15dB SM LC APC Variable Fiber Optic Attenuator Ion Doped
Single Mode 15dB SM LC APC Variable Fiber Optic Attenuator Ion Doped
Specifications
Brand Name :
CY/OEM
Place of Origin :
Hubei
MOQ :
1-10
Price :
0.47-2.5usd/pcs Can negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western
Supply Ability :
50000/week
Delivery Time :
5-8 work day
Packaging Details :
Individual Box
Attenuation Value :
1dB ~ 30dB
Certification :
IS09001-2015.ROHS
Model Number :
SM LC/APC
Description

Single Mode 15dB SM LC APC Variable Fiber Optic Attenuator Ion Doped

3dB SM LC / APC Fiber Optic Attenuator Attenuating Material - Ion Doped Fiber

Model Number::

LC

Return Loss::

UPC >55dB

Attenuation Accuracy:

1 ~ 7 DB ±0.5dB

High Light:

optical fiber attenuation

variable optical attenuator

Quick Detail:

Model Number: SM LC/APC

Return Loss: UPC >55dB

Attenuation Accuracy:8 ~ 12 dB ±0.7dB

Polarization Dependent Loss ≤0.1dB

Detail:

We offers an extensive line of dual wavelength (1310/1550nm) Singlemode fiber optic attenuators. These versatile in-line attenuators are the perfect solution for attenuating Singlemode fiber connectors for both lab and commercial applications. Constructed of the highest quality materials and factory tested, this series offers the widest array of connector styles and polish types.

Features:

  1. Single mode fiber connectors/connections

  2. fast and easy installation

  3. Ceramic ferrules provide precise alignment

  4. multi-application flexibility

  5. Attenuating material-Ion Doped Fiber

Applications:

Test and measurement

FTTX

Fiber optical CATV
Fiber optical sensor
Testing equipment

Specifications:

Attenuation Value 1dB ~ 30dB

Operating Wavelength 1240 ~ 1620nm (Dual 1310/1550nm)

Premium

Return Loss

UPC >55dB

APC >65dB

Attenuation

Accuracy

1 ~ 7 dB ±0.5dB

8 ~ 12 dB ±0.7dB

13 ~ 17 dB ±1.0dB

18 ~ 25 dB ±1.3dB

Maximum Optical Input Power 1000mW

Polarization Dependent Loss ≤0.1dB

Operating Temperature Range -40 to 75

Storage Temperature Range -40 to 85

Humidity 95%RH

Single Mode 15dB SM LC APC Variable Fiber Optic Attenuator Ion Doped

Competitive advantages

Hubei Chenyu Optoelectronics Technology Co., Ltd. strictly implements the ISO9001 quality management system. The company has good facilities and qualified human resource management personnel to ensure stable product quality and excellent performance; and with good after-sales service, it has won customers’ Trust, products are exported to Europe, America and Southeast Asia countries.
