Polyester Star Bag 150mm Dust Collector Filter Cage
Polyester Star Bag 150mm Dust Collector Filter Cage
Polyester Star Bag 150mm Dust Collector Filter Cage
Polyester Star Bag 150mm Dust Collector Filter Cage
Polyester Star Bag 150mm Dust Collector Filter Cage
Polyester Star Bag 150mm Dust Collector Filter Cage
Polyester Star Bag 150mm Dust Collector Filter Cage
Polyester Star Bag 150mm Dust Collector Filter Cage
Specifications
Brand Name :
17s
Model Number :
12 pleat star cage
Certification :
ISO
Place of Origin :
China
MOQ :
negotiable
Price :
negotiable
Supply Ability :
TBD
Delivery Time :
TBD
Packaging Details :
steel crates
Material :
mild steel, stainless steel, galvanized wire
Finish Treatment :
Silicon Coating, zinc ,electrophoresis coating
Spiders :
press spider
Diameter :
110mm, 120mm, 138mm, 144mm, 150mm and Customized
No. of Vertical Wire :
12pcs
Crate :
steel crate
MOQ :
Negotiable
Description

12 Pleat Polyester Star Filter Bag Cage Pleat Bag Cage Spider Cage Bag House PE Star Bag Cage

1. Specification
Star cage, also names pleat cage, spider cage, is the bone and framework of bag, supporting the bag running, is special designed and made for star bag. Star Cages are welded by special supporting rings (Spiders). We are specialized in Star Cages design, develop and process. We have own stretch line, cut line, weld line, coating line and check equipment. Providing a wide range of star filter cages for bag house collector, which improve the performance, efficiency and bottom line of the bag house dust collector and flue.

2. Overview

Style star cage / pleat cage / spider cage
Pleats No. 12 pleats
Material Q235 mild steel
Diameter 110, 120, 138 mm
Vertical Wire Number 12 pcs
Thickness 4 mm
Spider Type press Polyester Star Bag 150mm Dust Collector Filter Cage
Thickness 1.5 mm
Distance 150-250 mm
Length TBD mm
Structure one section
Joining Method No
Top Cap Type weld U shape top cap
Size be up to customers mm
Thickness 1-1.2 mm
Fix weld to cage
Venturi Size no mm
Thickness 1 mm
Fix weld to top cap 　
Bottom Cap Type press bottom cap
Size 102, 112, 130 mm
Thickness no mm
Fix no
Finishing Type silicon coating
Thickness 90-140 um
Color black
Pack steel crate

more spider options

Polyester Star Bag 150mm Dust Collector Filter Cage Polyester Star Bag 150mm Dust Collector Filter Cage

3. The Match of Star bags and Cages

Star filter cages are special designed to fit star bags, which is not like ordinary ones with tigh match. Star cages is a kind of loose match of star bags, which is good for deashing.

Match Of Star Bags and Star Cages

Cage Pleats Wire QTY Diameter (mm) Remark
cage bag
8 pleats 16 110 120 3.5 or 4mm vertical wires, also can we 8 pcs vertical wires for diameter 110 and120mm
120 130
138 150
144 155
150 160
12 pleats 12 110 120 4mm vertical wires
120 130
138 150
10 pleats 10 110 120 4mm vertical wires
120 130
138 150
144 155
150 160

4. Why Choose Us

1) over ten years experience in this field

2) very strict quality control management

3) perfect feed back from customers about quality,service,shipping etc

4) we have own factory, easy control of quality, leadtime, workmanship and IP protection

5) many big and famous customers buy our products consistently

6) strong R&D team, design and develop and product ability

7) QC and QA inspection before shipping

8) 100% products exported, know customers’ requires

9) Zero complain and claim of our products till now
