Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter
Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter
Specifications
Brand Name :
ZYD
Model Number :
ZYD-WMP20
Certification :
CE
Place of Origin :
Ningbo
MOQ :
1000pcs
Price :
USD6
Payment Terms :
T/T, L/C
Supply Ability :
100000PCS/MONTH
Delivery Time :
30DAYS
Packaging Details :
CARTON BOX
BODY MATERIAL :
Plastic
DN SIZE :
15mm;20mm;25mm
MIN. Flow rate :
0.03m3/h
Weight without connectors :
0.58kg;0.621kg;0.7kg
Water temperature :
≤40℃
Water pressure :
≤ 1.6Mpa
Usage :
Plumbing pipes
Length/Width/Height: :
165mm/98mm/105.5mm;190mm/98mm/107mm;260mm/98mm/107mm
Weight with connectors :
0.695kg;0.806kg;0.99kg
Body thread/Connector thread :
G3/4B,R1/2;G1B,R3/4;G11/4B,R1
Description

Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter

DESCRIPTION:

  • Dry type,magnetic drive,pointer-roller indicator.
  • Easy and long term clear reading,frost resistance,long working life etc.
  • Available with anti-magnet and remote output system by pulse on request.
  • Plastic meter's body and impact plastic ring.

SPECIFICATION:

  • Dry type,magnetic drive,pointer-roller indicator.
  • Easy and long term clear reading,frost resistance,long working life etc.
  • Available with anti-magnet and remote output system by pulse on request.
  • Plastic meter's body and impact plastic ring.
Standards Compliance
  • ISO 4064 Class B for horizontal installation.
  • AWWA for horizontal installation for selecting.
Optional Features
  • Several lengths and connections avaliable on request.
  • U.S. gallon (USG) for selecting.
  • Can be equipped with reed switch option.
Working Conditions
  • Ware temperature:≤40℃
  • Water pressure:≤1.6MPa
Dial Plate DN15~25
Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water MterMagnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter

Dimension Picture:

Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter

Main Technical Data

Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter

Flow Error Curve

Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter

Pressure Loss Curve

Magnet Seal GSM Electronic Remote Reading Baylan Wireless Block Sensus Activity Class C Flow Water Mter

Maximum Permissible Error (both class A and class B)

In the lower zone from Qmin inclusive up to but excluding Qt is ±5%.

In the upper zone from Qt inclusive up to and including Qmax is ±2%.

Installation Requirements

The meter should be installed in horizontal position with the register face upwards
Pipeline must be flushed before installation
The meter should be constantly full of water during operation
The meter must be installed with the direction of the flow as indicated by the arrow cast in the meter body.

Quality and inspection :

*We promise supply you high quanlity and durable goods for you.
*Our worker will check everyone accessories before hand-assembled
*Our quality inspector will check everyone product one by one before packing
*Regular checking on line from production in each workshop

Packaging and Shipping:

1) The package standard : standart export carton, box .

2) If customer has special requirement. it is available to provide

the colorful package against the design of customer.
