Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Silicone Protective Film Coating Machine Fast Deposition Speed For Car Lamps
Specifications
Brand Name :
ZYD
Model Number :
ZYD-1600
Certification :
CE
Place of Origin :
CHINA
MOQ :
1PCS
Price :
USD100000
Payment Terms :
T/T, L/C
Supply Ability :
10PCS/MONTH
Delivery Time :
50Days
Packaging Details :
NAKE PLASTIC COVER PACKING
Type :
Vacuum coating machine
Power :
210KW
Voltage :
380V
chamber size :
1200L
Water pressure :
≥0.2MPa
Air pressure :
0.5-0.8MPa
Description

Car Lamps Silicone Protective Film Coating Machine

Description:

1. Fast deposition speed and high production effiency ,coated film with excellent brightness and well adhesion.

2. Intelligent automatic control, easy to operate the machine without any experience.

3. Environment friendly ,no waste water and gas.

4. Manufacturing by CICEL latest technology,also approved CE and ISO international quality management system certification.

Specifications

car lamps coating machine
1. Certified ISO9001
2. Nice after-sales service
3. Strong technology
4. Size can be customized

Part name Specification Supplier Qty.
Vacuum chamber

ø1600mm×H2000mm

vertical with double doors

 ZYD 1set
Lining board 0.6mm, SUS304 ZYD 1set
Rotation system of workpiece Frequency regulation ZYD 1set
Evaporation power SCR ZYD 1set
Evaporating transformer 20KW GUANGDONG 1set
Glow ion cleaning Transformer system,13KW GUANGDONG 1set
Pipe system Standard equipment ZYD 1set
Vacuum gauge ZDF-5227 SICHUANG 1set

valve

 Main valve GDQ-900 ZYD 1set
Rough valve GDQ-200 ZYD 1set
Front valve GDQ-200 ZYD 1set

Vacuum

System

Diffusion pump KT-900 ZYD 1set
Mechanical pump H-150 TONGRI LTD 1set
Roots pump ZJY-1200A YANGGUANG LTD 1set
Holding pump 2X-30 NANGUANG LTD 1set
Intelligent program PLC controlled,CICEL program MITSUBISHI 1set
Electric element Standard equipment OMRON,DELIXI 1set
Man-machine interaction 10.4 inch,color touch screen XINJIE LTD 1set
Pump speed 5×10-²≤4.5mins Clean idle oven(no-lo
