CFK-A2090 CFK-A2595 CFK-A30102 Overrunning Clutch For Tractor One Way Roller Bearing
CFK-A2090 CFK-A2595 CFK-A30102 Overrunning Clutch For Tractor One Way Roller Bearing
CFK-A2090 CFK-A2595 CFK-A30102 Overrunning Clutch For Tractor One Way Roller Bearing
CFK-A2090 CFK-A2595 CFK-A30102 Overrunning Clutch For Tractor One Way Roller Bearing
CFK-A2090 CFK-A2595 CFK-A30102 Overrunning Clutch For Tractor One Way Roller Bearing
CFK-A2090 CFK-A2595 CFK-A30102 Overrunning Clutch For Tractor One Way Roller Bearing
Specifications
Brand Name :
Tianniu
Model Number :
CKF series
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C, D/A, D/P
Supply Ability :
10000 per month
Delivery Time :
5-10working days
Packaging Details :
Cartons by sea shipping by airplane
Certification :
ISO-9001
Name :
CKF Roller Type Overrunning Clutch Bearing
Material :
GCR 15 Bearing Steel
Type :
One way bearings
Thichness (mm) :
106-190
Torque (Nm） :
294-68600
Weight (Kg) :
2.1-16.5
Bore Size(mm) :
200-350
Description

CKF One Way Roller Type Bearing Overrunning Clutch Bearing for Industry

Production introduction

CKF-A is a non-contact one way sprag clutch bearing. The inner ring is designed for unidirectional function without bearing support. Sprag clutch bearing must be installed to ensure the coaxiality of the inner ring and outer ring when used.

When used for the purpose of preventing reversal, it is necessary to check that the speed must not be lower than the minimum allowable value for exceeding the speed, as shown in the table below.

This model is mainly used to prevent reversal under high speed working condition. It can also be used for high speed overrunning clutch and low speed wedge drive switching device.

Changzhou TIANNIU Transmission Equipment Co., Ltd (Changzhou TIANNIU Clutch Factory) is a professional one way clutch bearing supplier, the primary products are micro electromagnetic clutch, torque limiter coupling, sliding shaft coupling, flexible propeller shaft coupling, locking assembly and shaft couplings, etc.

We have been in Sprag Clutch Bearing and clutch one way bearing industry for more than 10years, persisting in the business principle of products tailored to requirements from clients.We service through listening to our customers, applying innovation and building with craftsmanship to meet all their needs.


Products Parameters
Type
Torque Nm		 Overrunning
Limited Speed r/min		 d[H7] D[h7] e[H7] F G C B A n-d1 bn*tn Weight
[kg]
out race inner race
CFK-A2090 140 875 6000 20 90 66 78 36 35 35 25 6-6.6 6×2.8 1.50
CFK-A2595 190 825 6000 25 95 70 82 40 35 35 25 6-6.6 8×3.3 1.60
CFK-A30102 340 780 6000 30 102 75 87 45 40 40 30 6-6.6 8×3.3 1.80
CFK-A35110 425 740 6000 35 110 82 96 52 40 40 30 6-6.6 10×3.3 2.10
CFK-A40125 625 720 5000 40 125 92 108 62 40 40 30 8-6.6 12×3.3 2.90
CFK-A45130 715 665 5000 45 130 94 112 64 40 40 30 8-9.0 14×3.8 3.10
CFK-A50150 1120 610 4000 50 150 114 132 84 40 40 30 8-9.0 14×3.8 4.70
CFK-A55160 1300 600 4000 55 160 116 138 86 45 45 34 8-9.0 16×4.3 5.40
CFK-A60175 1500 490 3200 60 175 135 155 95 70 60 47 8-11.0 18×4.4 8.5
CFK-A70190 2250 480 3200 70 190 140 165 100 70 60 47 12-11.0 20×4.9 10
CFK-A80210 3000 450 2400 80 210 160 185 120 80 70 48 12-11.0 22×5.4 14
CFK-A90230 4600 420 2400 90 230 180 206 140 90 80 67 12-13.5 25×5.4 19
CFK-A100280 7600 455 2000 100 280 200 240 160 105 100 67 12-17.5 28×6.4 34
CFK-A130320 13600 415 2000 130 320 235 278 195 105 100 67 12-17.5 32×7.4 44
CFK-A150400 24500 365 2000 150 400 320 360 256 105 100 86 12-17.5 36×8.4 73

CFK-A2090 CFK-A2595 CFK-A30102 Overrunning Clutch For Tractor One Way Roller Bearing
